Powercut105 Inverter Automated Plasma Cutting Machine
Powercut105 Inverter Automated Plasma Cutting Machine
Specifications
Brand Name :
GENWELD
Model Number :
Powercut105
Place of Origin :
Chongqing, China
MOQ :
50
Payment Terms :
T/T
Supply Ability :
2000//month
Packaging Details :
675× 315×605
Description
Powercut seriesis plasma cutting machine without high frequency, cannot be used as handheld cutting process, but
especially suitable for automatic cutting system such as CNC and robot cutting machine. There is both digital interface
and analoginterfaceon themachine,workwell withmostautomaticcutting equipment.
Main Features
Non high frequency arcstriking mode without HF interference
■ High duty cycle for heavy industry use
■ With three working process of standard cutting, grid plate cutting and plasma gouging
■ W ith digital soft switch invertertechnology, get precise parameters control
■ W ith recording function for consumables workinglife and piercing times
■ W ith automatic gas pressure checking function to protect the plasma torch well
■ W ith automatic protection of over-heating and lackvoltage
■ With analog connectors and RS485 digital communication connectors, can equip
various CNC control systems
Product Application
■ It's mainly used in cutting process of carbon steel, alloy steel and
nonferrous steel
Main Technical Parameters
ltem Unit Model
Powercut105
Input Power V/Hz 3~380±15%50/60
Rated Input Current A 35.6
Rated Input Capacity KVA 23.4
Rated Open Circuit Voltage V 348
Rated Duty Cycle 100%(40℃)
Rated Output Current/Voltage A/V 105/160
Power Factor 0.76
Efficiency 94.3%
Output Current Adjust Range A 30~105
Arc Voltage Output Ratio 1:1/1:20/1:21.1/1:30/1:40/1:50(Default 1:50)
Arc Strike Mode Non-High Frequency Striking
Quality Cut Thickness (Carbon Steel) mm 22
Piercing Thickness (Carbon Steel) mm 22
Severance Cut Thickness (Carbon Steel) mm 40
Insulation Grade F
Power Source Cooling Mode Air Cooling
Torch Cooling Mode Air Cooling
Ingress Protection IP21S
Dimension (L×W×H) mm 675×315×605
Net Weight Kg 46
