LGK-63/100/160/200/400MA Inverter Handheld Air Plasma Cutting Machine
LGK-63/100/160/200/400MA Inverter Handheld Air Plasma Cutting Machine
LGK-63/100/160/200/400MA Inverter Handheld Air Plasma Cutting Machine
LGK-63/100/160/200/400MA Inverter Handheld Air Plasma Cutting Machine
Specifications
Brand Name :
GENWEKD
Model Number :
LGK-63/100/160/200/400MA
Place of Origin :
Chongqing, China
MOQ :
50
Payment Terms :
T/T
Supply Ability :
1000/month
Packaging Details :
530×280×485/675x320x605/900x410x1000/1110x480x1015
Description

LGK-63/100/160/200/400MA Inverter Handheld Air Plasma Cutting Machine

Product Application


■ Suit manual cut for carbon steel,alloy steel and nonferrous steel

Main Technical Parameters
ltem Unit Model
LGK-63MA LGK-100MA LGK-160MA LGK-200MA LGK-400MA
Input Power V/Hz 3~380±15%50/60
Rated Input Capacity KVA 9.3 15.8 25 40.8 81.2
Rated InputCurrent A 14.5 24 38 48 73
Rated Open CircuitVoltage V 265 300 316 360 370
Rated Duty Cycle 60%(40℃) 35%(40℃)
Efficiency 93% 89% 93% 93% 92%
Power Factor 0.76 0.85 0.78 0.79 0.91
Output Current Adjust Range A 30~63 30~100 40~160 40~200 60~400
Quality Cut Thickness (Carbon Steel) mm 15 25 30 35 50
Max.Cut Thickness (Carbon Steel) mm 25 40 60 70 120
Arc Strike Mode Contact Non-Contact
Plasma Gas Air
Air Pressure MPa 0.3~0.5 0.4~0.6
Torch Cooling Mode Air Cooling Water Cooling
Power Source Cooling Mode Air Cooling
Insulation Grade F
Ingress Protection IP21S
Dimension(LxWxH) mm 530×280×485 675x320x605 900x410x1000 1110x480x1015
Net Weight Kg 25 30 48 100 150
