ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0
ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0
ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0
ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0
ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0
ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0
ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0
ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0
Specifications
Brand Name :
JTP
Model Number :
6HH1
Certifiion :
ISO9001:2008;ISO/TS16949:2009
Place of Origin :
China
MOQ :
1 SET
Price :
negotiation
Payment Terms :
T/T or western Union
Supply Ability :
5000pcs per month
Delivery Time :
Usually within one week after receive payment
Packaging Details :
Packed in carton firstly,and then reinforced with green sack for outer packing
OEM :
8-94390-799-0
CYL :
6
CAR MAKE :
ISUZU
DIA :
115mm
1st RING :
3.5mm
2nd :
2.5mm
OIL RING :
4.0mm
Description

Fit industrial engine parts for ISUZU 6HH1 auto engine piston ring dia 115mm

Specifiions:

Details For Engine 6 Cylinder 6HH1 6HH1T Diesel Engine Piston Rings:


6HH1
Appliion: FORWARD
No. CyI: 6
Diameter: 110.0MM
Piston OEM No. Compress Height Total Length Pin Size Feature
8-94390-798-0 62.6 106.5 36x79 w/al-fin
Piston Ring OEM No. Size1 Size2
8-94390-799-0 3.5+2.5+4.0
Cylinder Liner OEM No. Size Flange
8-94391-602-1 115.0x118.0x210.0 123.7x6.0
Engine Bearing OEM No. Main Bearing Con Rod Bearing Bush
8-94393-327 8-97045-800 1-12251-036
Engine Valve (IN) OEM No. Head Diameter Stem Diameter Total Length
8-94395-112-0 50.0 9.0 141.0
Engine Valve (EX) OEM No. Head Diameter Stem Diameter Total Length
8-97019-337-0 42.0 9.0 140.5

Our products:

1. Material:

boron-copper chrome cast iron alloy,boron alloy,steel, etc.

2. Treating:

phosphated, nitrided, laser treatment, quenching, chrome plated, etc.

3. Performance:

High wear and corrosion resistance,good dimensional stability.


Description:

Engine c.c. Vehicle Model TEIKUKO Product Code Cyl Position 　 Size (mm) 　 shape Material Surface Reference
　 　 　 d1 h1 a1 　
Chassis Type TEIKUKO Series No. No. (D) (B) (T) Treatment
6SA-T 4751 Truck TEIKUKO-AD-30291 6 1 115 3 4.6 BF HB 4Cr 1-12121-070-0
6SA-1 Forward 200PS 　 2 115 2.5 4.8 TUC HB Cr 1-12121-113-0
　 　 　 　 　 0 115 4 4.2 E-BC3 HB Cr 1-12121-750-0/lcyl
4HG1 4751 Truck TEIKUKO-AD-30292 4 1 115 3 4.15 BF-K2 SR Cr 8-97105-867-0
4HJ1 NPR 　 2 115 2.5 4.8 TUC CR Cr 8-97219-054-0
　 　 　 　 　 0 115 4 4.35 E-BC16 SR GN 　
6HH1 8226 Forward TEIKUKO-AD-30293 6 1 115 3.5 4.6 BF HB 4Cr 8-94390-799-0/lcyl
　 Journey 　 2 115 2.5 4.8 TUC CR Cr 8-94390-733-2/lcyl
　 　 　 　 0 115 4 4.35 E-BC16 SR GN 　
　 　 TEIKUKO-AD-30294 　 1 115 3.5 4.6 BF HB 4Cr 8-94392-128-1/cyl
　 　 　 2 115 2.5 4.8 TUC CR Cr 　
　 　 　 　 　 0 115 3 3 E-BC16 SR GN 　
6HK1-TC 7790 Erga TEIKUKO-AD-30295 6 1 115 2.948 4.3 BF-K1 SR Cr 8-94391-502-3/cyl
　 　 　 2 115 2 4.3 T1-IB SR GN 　
　 　 　 3 115 2.5 4.8 TUC CR Cr 　
　 　 　 　 　 0 115 3 3 E-BC16 SR GN 　
6HL1-IC 7166 Forward TEIKUKO-AD-30296 6 1 115 2.948 4.25 BF-K1 SR Cr 8-97601-318-1
　 　 　 2 115 2.5 4.8 T1-IC CR Fe 　
　 　 　 　 　 0 115 3 3 E-BC16 SR GN 　
4HF1-LPG 4334 Elf TEIKUKO-AD-30297 4 1 115 3 4.5 BF HB 4Cr 8-97258-337-0
　 　 　 2 115 2.5 4.8 TUC CR Cr 　
　 　 　 　 　 0 115 3 3 E-BC16 SR GN 　
4HL 4777 Elf TEIKUKO-AD-30298 4 1 115 3 4.3 BF SR Cr 8-97331-641-0/cyl
　 　 　 2 115 2 4.25 T1 SR Cr 　
　 　 　 　 　 0 115 3 3.1 E-BC16 SR GN 　
10PC1 15014 CXR 10.75ton TEIKUKO-AD-30299 V-10 1 119 3 4.6 BF HB 4Cr 1-12121-047-0/lcyl
　 　 　 2 119 2.5 4.8 T1 CR Cr 　
　 　 　 　 　 0 119 4 5 E-C2 HB Cr 　
8PC1-T 12011 CXM 10.75ton TEIKUKO-AD-30300 V-8 1 119 3 4.6 BF HB 4Cr 1-12121-049-0/lcyl
　 　 　 2 119 2.5 4.8 TUC HB Cr 　
　 　 　 　 　 0 119 4 5 E-C2 HB Cr 　
10PC1-T 15014 Truck TEIKUKO-AD-30301 V-10 1 119 4 4.6 BF HB 4Cr 1-12121-062-0/lcyl
　 Bus 　 2 119 2.5 4.8 TUC HB Cr 　
　 　 Hi-Decker 　 　 0 119 4 5 E-C2 HB Cr 　
DH100 10179 TD TEIKUKO-AD-30302 6 1 120 3 5 BF CR 4Cr 12181-050
　 SLR 　 2 120 3 5 T1 CR Fe 12180-068
　 BL 　 3 120 3 5 T1 CR Fe 　
　 　 　 O1 120 6 3.7 E-BC3 CR Cr 　
　 　 　 　 　 O2 120 6 4.8 C1 CR Fe 　
DH100BU 10179 　 TEIKUKO-AD-30303 6 1 119.5 3 4.9 BF HB 4Cr 1-12121-030-0
　 　 　 2 119.5 3 5 T1 CR Fe 　
　 　 　 　 　 0 119.5 6 5.6 E-BC3 CR Cr 　
DH100 Truck TEIKUKO-AD-30304 6 1 120 3 4.9 BF HB 4Cr 1-12181-001-0
　 TD70E TD80E 　 2 120 3 5 T1 CR Fe 1-12181-083-0
　 TD90E TD141 　 3 120 3 5 TUC CR Fe 1-12181-086-0
　 TP70E TP81 　 0 120 6 3.7 E-BC3 CR Cr 1-12181-114-0
　 TP81E TP91E 　 　 　 　 1-12121-016-0/lcyl
　 Bus 　 　 　 　 　
　 BC30 BC141 　 　 　 　 　
　 BC151 BC151P 　 　 　 　 　
　 BC161 　 　 　 　 　
　 BU05 BU10 　 　 　 　 　
　 BU15 BU20 　 　 　 　 　

Our sevice:
100% quality assurance, develop and manufacture follow original ones;
Reasonable stock and timely delivery;
Quick response within 24 hours ;
Long-term strong and steady supplying ability;
Ensure the best quality;
The first-class logistics & Ensure that your goods arrived safely;
Goods will Be packed safe & carefully;
Good After-sales service.Track usage.Positive feedback response;
Establish inquiry library for you, we are your professional sourcing consultant;

Our excellemt quality products and excellent service will meet your requirements. Your satisfaction is our priority.

Packaging&Shipping:
Neutral packaging or according to customers requirment.

After your full payment,we will delivery your goods in one working day.

6HH1 PISTON RING PICTURE AS BELOW:

ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0


We also have a range of other spare parts for your choose:

ISUZU 6HH1 Piston Ring Sets For Industrial Engine Parts Dia 115mm OEM 8-94390-799-0


WELCOME YOUR ENQUIRY, WE WILL ALWAYS BE HERE SERVICE FOR YOU!
