Automatic Electric Steam Generator Boilers For Medical Or Industry Heating By Stainless Steel Housing & High Efficiency
Steam Generator Boilers description:
Steam Generator Boilers is also called a steam boiler, which uses the thermal energy of the fuel or other energy to become a mechanical equipment for hot water or steam. According to the fuel classification, it can be divided into an electric steam generator, electromagnetic steam generator, fuel steam boiler, gas steam boiler, etc. Can be widely used in various types of industries that require steam or thermal energy.
heated steam generators Quick Detail:
· Stainless steel housing
· 6-144KW various specifications
· Steam boiler is fully automatic
· Thermal efficiency 98%
· Come out of steam in 5 minutes
· 6 security protection
· Up to 15% energy savings
· 1 Year Warranty
Specifications:
Steam Generator Boilers (ALJ-380)
Model | ALJ-380-24kw |
Rated steam capacity | 32kg/h |
Rated pressure | 0.7Mpa |
Steam temperature | 171ºC |
Power | 24kw |
Water capacity | 26L |
Design thermal efficiency | 98% |
Steam outlet | DN15 |
Water inlet | DN15 |
Blow down valve | DN15 |
Safety valve | DN15 |
Rated voltage | 380V 50HZ |
Product size L*W*H | 700*460*1050mm |
Weight | 65kg |
Steam Generator Boilers Advantages:
1. Elesteam brand steam generator has nearly 100% thermal efficiency with original energy conservation system, reducing heat loss, saving electricity more than 15% .
2. The smart mini electric steam boiler with steam capacity 65kg/h are smart fully automatic operated with accurate computerized circuit board.
3. Safer than ever with 6 protection systems: pressure regulator system, Overpressure automatic protection, water lack protection, dry-fire protection, problem alarm system, overheat system.
4. Almost instant steam within 5 minutes
The electric steam boiler adopts high quality electrical heated tube which heats the water rapidly . It uses stainless steel material with high compression strength, the working life is 5~10 times longer than common tubes.
5. Easy to install and assemble
What you need to do is only connecting the steam generator to your device with a pipe which can output the steam .
6.Intelligent
Advanced steam boiler special computer control board, with boiler water level intelligent control, steam pressure control, low water level alarm and protection, automatic heating to reach the water level, steam pressure ultra high alarm and protection and other automatic control functions.
Steam Generator Boilers Applications :
The Steam Generator Boilers can be widely used in Laundering , washing,Food processing,Industrial washing,Sauna bath room,Biological and medical industry,Sterilization and hygiene,Clothing ironing.
1. Laundering , washing
2. Food proccessing
3.Industrial washing
4. Sauna bath room
5. Biological and medical industry
6. Sterilization and hygiene
Advanced and sophisticated components
