Operation panel
All operation is automatic and smart, you just need to press the button to maneuver the steam generator machine. Easy to operate for high efficiency. Our advantages
1. Super cleaning performance: with high pressure steam, the steam washer can strongly clean the srface of cars and industrial equipments.
Power | 24 kw |
Evaporation | 32 kg/h |
Voltage | 220V/380 V |
Rated Pressure | 0.7-1 Mpa |
Steam temperature | 110-185℃ (original steam) 60-70 ℃ ( ejected steam ) |
Power Consumption | 2 kW.h/car |
Water Consumption | 3 L |
Dimension | 800*400*820 mm (L*W*H) |
Advanced operation and control system
Portable lifting bar
Rational pipe system
Power/ Type | 6 kW | 9 kW | 12 kW | 18 kW | 24 kW | ||||
Voltage | 220V/380V | 220V/380V | 220V/380V | 220V/380V | 220V/380V | ||||
Evaporation | 8 kg/h | 12 kg/h | 16 kg/h | 24 kg/h | 32 kg/h | ||||
Rated Pressure | 1 Mpa | 1 Mpa | 1 Mpa | 1 Mpa | 1 Mpa | ||||
Water Consumption | 3 L | | | | | ||||
Washing Efficiency | 20 minutes/car | | | | | ||||
Steam Temperature | 60—70 ℃ | | | | | ||||
Dimension | 800*400*820 mm | | | | | ||||
Applicable steam guns | 1 | 1 | 2 | 2 | 3 | ||||
Weight | 65 kg | 68 kg | 70 kg | 73 kg | 78 kg | ||||
Pipe length | 10 m | | | | | ||||
Water&steam regulator | 1 | | | | |
