Product Description:

Bag dust collectors are designed to filter dust-containing gas using textile filter cloth or non-textile felt. These bags use the filtering effect of fiber fabrics to trap all the dust, to ensure the gas is clean and safe. When the dust-containing gas flows into the bag dust collector, large particles and heavy dust decrease in speed due to gravity and fall into the ash hopper.

The filtering process of a bag dust collector begins when the dust-containing gas enters the ash hopper through the guide plate from the lower air intake pipe of the dust collector. Guide plates are essential in reducing the gas velocity and the coarse dust fall into the hopper while the remaining fine dust particles enter the filter bag chamber with the gas.

Due to the effects of the filter material fiber and fabric such as inertia, diffusion, barrier, hooking, and static electricity, the dust is retained in the filter bag, and the purified gas escapes from the bag and is discharged through the exhaust pipe. The filter bag's accumulated dust is removed using gas backwashing, and the cleaned dust goes down to the ash hopper and is discharged to the ash conveying device through the double-layer ash unloading valve.

In a bag dust collector, a pulse of airflow can also be used to remove dust. The cleaned dust is discharged by the dust discharge device. Bag dust collectors are known for their high dust removal efficiency, wide range of air volume, filtration accuracy, economy, and high-temperature resistance. Additionally, they are not affected by dust and resistance characteristics, have a suitable structure, and are stable in operation.

1. High dust removal efficiency: generally above 99%, the dust concentration of the dust collector outlet gas is within tens of mg/m3;
2. Wide range of air volume: small only a few m3 per minute, large up to tens of thousands of m3 per minute, can be used for flue gas dust removal in industrial furnaces to reduce the emission of atmospheric pollutants;
3. High filtration accuracy: filtration accuracy 0.3μm, air leakage rate < 0.1%, ultra-clean emission;
4. Strong economy: Under the premise of ensuring the same high dust removal efficiency, the cost is lower than that of the electrostatic precipitator;
5. High temperature resistance: When using high-temperature resistant filter materials such as glass fiber, polytetrafluoroethylene, P84, etc., it can operate under high temperature conditions above 200℃;
6. Strong adaptability: insensitive to the characteristics of dust, not affected by dust and resistance;
7. Suitable structure: The system structure is compact and occupies a small area;
8. Stable operation: Applicable to hundreds of working conditions, reliable operation, and long service life.

Applications:

This product is designed to provide strong cleaning ability, thanks to its advanced technology that uses pulsed airflow to remove dust from the bag. This ensures that the dust collector operates efficiently while maintaining a high level of cleaning performance.

With its electric power source and PLC control system, the Pulse bag dust collector is easy to operate and maintain. It is also highly customizable, making it suitable for various industries such as metalworking, woodworking, pharmaceuticals, food processing, and others.

The product's airflow capacity ranges from 1000-100000 cubic meters per hour, making it ideal for small and large-scale operations. It can effectively collect dust and debris from different sources, including industrial machines, production lines, and ventilation systems.

Overall, the Pulse bag dust collector product by Delong Environmental Protection is an excellent choice for those looking for a high-quality, efficient, and reliable dust collector. Its strong cleaning ability, using pulsed airflow, is perfect for various application occasions and scenarios, making it a must-have for industries that require clean and safe working environments.

Support and Services:

The Pulse bag dust collector is designed to provide efficient and reliable dust collection for a variety of industrial applications. Our technical support and services team is dedicated to ensuring that our customers receive the best possible support throughout the life of their equipment. Some of the services we offer include:

• Installation and startup assistance
• On-site training for operators and maintenance personnel
• Regular maintenance and inspection services
• Emergency repair and replacement services
• Upgrades and retrofits to keep equipment up-to-date with changing regulations and industry standards

Our team of experienced technicians is available to provide comprehensive technical support and services to help ensure that your Pulse bag dust collector operates at peak efficiency and continues to meet your needs for years to come.

Packing and Shipping:

Product Packaging:

The Pulse bag dust collector will be packed securely in a heavy-duty cardboard box with foam padding to prevent any damage during transit. The product will be wrapped in a plastic bag to protect it from dust and moisture. The package will also include an instruction manual and all necessary hardware for installation.

Shipping:

The Pulse bag dust collector will be shipped via a reputable courier service. We offer free standard shipping to all customers within the United States. For international orders, shipping fees will be calculated at checkout based on the destination country and package weight. Once shipped, customers will receive a tracking number via email to track their package's delivery status.
