1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers
1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers
1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers
1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers
1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers
1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers
1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers
1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers
Specifications
Brand Name :
BOTO
Model Number :
B-TH-1000E
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1 set
Payment Terms :
T/T, Western Union
Supply Ability :
800 set/year
Delivery Time :
15-30days
Packaging Details :
strong wooden case
Internal size :
100x100x100 cm
External size :
130(W)x190(H)x123(D) cm
Relative humidity :
20%-98%RH
Temp range :
-70℃~150℃
Temp rising time :
About 3~5℃/min
Temp falling time :
About 0.7℃~1℃/min
Temp fluctuation :
±0.5℃
Temp uniformity :
±1℃
Temp&humidity deviation :
±1℃ / ±3%RH
Internal material :
304 stainless steel plate
Exteral material :
coating or 304 stainless steel plate
Voltage & frequency :
380V 50/60Hz
Power :
4KW~10KW
Description

1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers

The temperature and humidity test chamber can accurately simulate the complex natural environment of low temperature, high temperature, high humidity, low temperature and low humidity, which is suitable for the product detection of plastics, electronics, food, clothing, vehicles, metals, chemicals, building materials and other industries.

TH-XX-X series depends on different temperature and volume needs.

XX represents the volume of the chamber and it can be 80,120,225,408,504,800 and 1000.

X represents the low temperature of the temp range and it can be A 0℃,B -20℃, C -40℃,D -60℃ and E -70℃.

Model B-TH-80 B-TH-120 B-TH-225 B-TH-408 B-TH-504 B-TH-800 B-TH-1000
Volume (V) 80 L 120L 225L 408L 504L 800L 1000L
Temperature range

A: 0°C ~150°C

B:-20°C~150°C

C: -40°C~150°C

D: -60°C~150°C

E: -70°C~150°C

Customized temperature is available.

1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers

BOTO product characteristics:

1.The import of compressors and refrigeration accessories by the well-know brands in the national boundaries ensures the stability of the refrigeration system.

2.The cause of the faults can be displayed and the reason is easy to exclude.

3.The special air supply cycle design, the temperature and humidity distribution uniformity is good.

4.The whole series of imported microcomputer controllers are colored. Color touch screen, Chinese and English system, can be used as a function of setting the city value. It can show the cause of the trouble, exclude easy, super quiet design, effectively reduce the running noise of the equipment, and

5.Super quiet design, effectively reduce the running noise of the equipment.

6.Multiple safety protection, refrigerant high voltage protection, compressor overload protection, current overload protection, over temperature protection, leakage protection.

1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers

Standards: GB/T2423/5170/10586, JIS C60068, ASTM D4714, CNS3625/12565/12566

Technical specification:

Model B-TH-1000

Inner chamber size

W×H×D(cm)

 100×100×80

Outside Size

W×H×D(cm)

 130X190X123
Volume (V) 1000L
Temperature range

A: 0°C ~150°C

B:-20°C~150°C

C: -40°C~150°C

D: -60°C~150°C

E: -70°C~150°C

Customized temperature is available.
Humidity range

RH20%-98%

Customized humidity is available.
Function Fluctuation ±0.5°C ±2.5%RH
Deviation ±0.5°C-±2°C ±3%RH(>75%RH); ±5%RH(≤75%RH)

Controller

Analytical

Accuracy

 ±0.3°C ±2.5%RH
Wind Cycling Way Centrifugal fan-broadband type forced air circulation
Refrigeration Way Single stage compression refrigeration
Refrigerator French Tecumseh
Refrigerants R4O4A USA DuPont environmental protection refrigerant(R23+R404)
Condensing Way Air-cooled or water-cooled
Water Supplying Way Automatic cycling water supply
Safety device

Non- fuse-switch(compressor overload,

refrigerant high low voltage,

over-humidity and temperature protection,

Protection switch,fuse stoppage warning system

1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers

1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers

Shanghai BOTO GROUP LTD is a high technology company specializing in integrated incubation systems. We are conveniently located in Shanghai City.

Based on the 30 years of incubator R&D experience from our technical team,our main and hot sales products are the high and low temperature&humidity test chamber.We have cooperated with military, semiconductor, aerospace industry and vehicle manufacturer on the world for a long time.

1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers

1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers

1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers

1000L Environmental Programmable Humidity Chamber For Products Life Span Test environmental test chambers
