Programmable Temperature Humidity Climate Test Chamber Price
Programmable Temperature Humidity Climate Test Chamber Price
Specifications
Brand Name :
BOTO
Model Number :
BT-LR-B001
Certification :
CE ISO
Place of Origin :
China
MOQ :
1set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 Piece/Pieces per Month
Delivery Time :
5-10days
Packaging Details :
wooden case
Power: :
Electronic
Description

Programmable Temperature Humidity Climate Test Chamber Price

Describe purpose

This test chamber provides high temperature, low temperature, high humidity, low humidity simulation environment, to test the rubber, plastic, electronic products before and after the test material and strength reduction degree.The machine can also simulate the container environment to detect the fading and shrinkage of rubber and plastic under high temperature and humidity.Test heat, cold, dry and moisture resistance of various materials.Suitable for electronic, electrical, batteries, universities, research institutes, inspection and quarantine bureau, paper products, food, vehicles, auto parts, metal, chemical, building materials and other industries factory unit quality control testing.

Programmable Temperature Humidity Climate Test Chamber Price

Programmable Temperature Humidity Climate Test Chamber Price

Design Standard:

GB11158 High Temperature Test Chamber Technical Condition
GB10589-89 Low Temperature Test Chamber Technical Condition
GB10592-89 High-low Temperature Test Chamber Technical Condition
GB/T10586-89 Damp Heat Test Chamber Technical Condition
GB/T2423.1-2001 Low Temperature Test Chamber Test Methods
GB/T2423.2-2001 High Temperature Test Chamber Test Methods
GB/T2423.3-93 Damp Heat Test Chamber Test Methods
GB/T2423.4-93 Alternating Damp-Heat Test Methods
GB/T2423.22-2001 Temperature Changing Test Methods
IEC60068-2-1.1990 Low Temperature Test Chamber Test Methods
IEC60068-2-2.1974 High Temperature Test Chamber Test Methods
GJB150.3 High Temperature Test Methods
GJB150.4 Low Temperature Test Methods
GJB150.9 Damp Heat Test Methods

60068-2-1

Uses:

This equipment can simulate different environment condition. It's appropriate for testing material performance, such as resist heat, resist dry,resist humidity and resist cold. That can define performance of material.

Programmable Temperature Humidity Climate Test Chamber Price

Specification

Model BT-LR-B001-80
(A~F)		 BT-LR-B001-150L
(A~F)		 BT-LR-B001-225L
(A~F)		 BT-LR-B001-408L
(A~F)		 BT-LR-B001-800L
(A~F)		 BT-LR-B001-1000L
(A~F)
Inner size: WHD(cm) 40*50*40 50*60*50 60*75*50 60*85*80 100*100*80 100*100*100
External size: WHD(cm) 105*165*98 105*175*108 115*190*108 135*200*115 155*215*135 155*215*155
Temperature range (Low temp.:A:+25℃; B:0℃;C:-20℃; D:-40℃; E:-60℃; F:-70℃) (High temp.: + 150℃)
Humidity range 20%~98% R.H
Temp analytic accuracy/
uniformity		 0.1℃/±2.0℃
Temperature Fluctuation ±0.5℃
Humidity control accuracy ±0.1%;±2.5%
Heat, cooling time Heat up about 4.0°C/min ; Cooling about 1.0°C/min
Inner and outer materials SUS#304 Stainless steel for inner chamber ; Carton Advanced cold plate nano paint for outer
Insulation materials Resistant to high temp ,high density,formate chlorine,ethyl acetum foam insulation materials
Cooling system

Air cooling/single segment compressor(-40°C) ,air and water double segment compressor

(-50°C~-70°C)
Protection devices

Fuse switch, compressor overload switch, refrigerant high and low pressure protection switch,

super humidity over-temperature protection switch, fuse, failure warning system
Parts Watching window , 50mm testing hole , PL internal bulbs , Wet and dry bulb gauze , partition plate , castorx4, Foot Cupx4
Compressor Original France“Tecumseh”brand
Controller Taiwan, Independent R&D software
Power AC220V 50/60Hz & 1 , AC380V 50/60Hz 3
Weight (kg) 170 220 270 320 450

580
