High and Low Temperature Alternation Temperature Humidity Climatic Test Chamber Environmental Chambers
High and Low Temperature Alternation Temperature Humidity Climatic Test Chamber Environmental Chambers
High and Low Temperature Alternation Temperature Humidity Climatic Test Chamber Environmental Chambers
High and Low Temperature Alternation Temperature Humidity Climatic Test Chamber Environmental Chambers
Specifications
Brand Name :
DGBELL
Model Number :
BTHW-15m
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
Western Union, T/T, D/P, D/A, L/C
Supply Ability :
500 Sets per Month
Delivery Time :
Negotiation
Packaging Details :
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual inside.
Keywords :
Climatic Test Chamber for Battery
Inner Box Size :
W3000×H2000×D2500 (mm)
External Dimensions :
W4600×H2480×D2800(mm)
Humidity Range :
20%RH~98%RH Low humidity requirement: minimum can reach 5%RH
Temperature Fluctuation :
≤±0.5ºC
Temperature Deviation :
≤±2.0ºC
Temperature Uniformity :
≤±2.0ºC
Humidity Fluctuation :
≤±2.5ºC
Humidity Deviation :
Humidity>75%RH:≤+2,-3%RH;Humidity<75%RH:≤±5%RH
Temperature Rise Rate :
≥3ºC/MIN
Description

High and Low Temperature Alternation Temperature Humidity Climatic Test Chamber Environmental Chambers

Technical Parameters

Product Model

BTHW-15m³ (or 8m³, 10m³, 12m³, 30m³, 80m³)

Inner Box Size

W3000×H2000×D2500 (mm)

External Dimensions

W4600×H2480×D2800(mm)

Temperature Range

A type: 0 ºC ~ +120 ºC, B type: -20 ºC ~ +120 ºC, C type: -40 ºC ~ +10 ºC, D type: -60 ºC ~ +10 ºC (adjustable)

Humidity Range

20%RH~98%RH Low humidity requirement: minimum can reach 5%RH

Temperature Fluctuation

≤±0.5ºC

Temperature Deviation

≤±2.0ºC

Temperature Uniformity

≤±2.0ºC

Humidity Fluctuation

≤±2.5ºC

Humidity Deviation

Humidity>75%RH:≤+2,-3%RH;Humidity<75%RH:≤±5%RH

Temperature Rise Rate

≥3ºC/MIN

Cooling Rate

≥1ºC/MIN

Control System

PLC + touch screen control, network, with USB interface, with 485 interface can be connected to computer control, special network control software, convenient remote monitoring, data acquisition.

Cooling Method

Water-cooled

Wiring Hole

Diameter 100MM, quantity 2 sets or more

Other Requirements

Sub-carriage for easy access of products to equipment

Explosion-proof lighting system

Explosion-proof pressure relief system

Smoke exhaust system

Automatic water replenishment system

Fire extinguishing devices, sprinklers, smoke alarm devices, etc.
