High Temperature Accelerated Aging Burn In Test Chamber IEC 60068-2-2:2007
High Temperature Accelerated Aging Burn In Test Chamber IEC 60068-2-2:2007
High Temperature Accelerated Aging Burn In Test Chamber IEC 60068-2-2:2007
High Temperature Accelerated Aging Burn In Test Chamber IEC 60068-2-2:2007
Specifications
Brand Name :
DGBELL
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union, L/C, D/A, D/P
Supply Ability :
100 Sets per Month
Packaging Details :
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual inside.
Keyword :
burn-in test equipment,Burn in tester,Burn in test electronics
Temperature Deviation (No Load) :
≤±2ºC
Supply Voltage Range :
3V ~ 3.6V Adjustable
Current Detection Accuracy :
≤ ± 0.1mA
Specification :
≥ 520L
Temperature Deviation (Full Load) :
≤±5ºC
Voltage Output Fluctuation :
≤ ± 0.2V
Description

Laboratory Optical Module Environmental High Temperature Accelerated Aging Burn in Test Chamber Manufacturers

Applications of burn-in chambers

DGBELL's burn-in chambers are widely used for constant temperature reliability testing of automotive parts, electronic and electrical products, components and materials. It can also be used for other objects that require high temperature testing, such as pharmaceuticals, aircraft, etc. Our burn-in chambers can be customized according to your requirements, so if you have special needs, don't hesitate to contact us.

Advantages of burn-in chamber

SUS#304 high temperature resistant stainless steel
Fire-resistant, high-strength glass fiber insulation material
Control system and control circuit all adopt famous brand products
Double-sided cold-rolled plate electrostatic powder coating material

Standard

IEC 60068-2-2:2007

Technical Parameters

Temperature setting range Room temperature~100ºC
Fluctuation range (no load) ≤±1ºC
Temperature distribution uniformity (no load) Full load ≤ ± 3 ºC, no load ≤ ± 2 ºC
Temperature deviation (no load) ≤±2ºC
Temperature deviation (full load) ≤±5ºC
Supply voltage range 3V ~ 3.6V adjustable
Voltage output fluctuation ≤ ± 0.2V
Channel drive capacity ≤ 4000mA, and the need to provide overcurrent protection function
Current detection accuracy ≤ ± 0.1mA
Voltage detection accuracy ≤±4mV
With anti ESD / EOS capability With anti-ESD / EOS capability
Monitoring capability Can real-time monitoring of aging module products SN, DDM_TX, DDM_RX, Icc, Ibias, temperature, voltage and other parameters
Equipment functions Experimental temperature, current, voltage, time, over-temperature protection conditions can be freely set, data requirements can be exported in real time, the equipment aging normal operation of the box door automatically lock does not allow the opening of the box (automatic lock door way can be communicated)
Communication interface With data networking upload interface, must be with LAN interface, RJ45/RS232/GPIB contains at least one of them, can be docked to our server to achieve data upload, the specific implementation mode and format can be communicated.
Box volume ≥ 520L
Optical module power supply 3.0 ~ 3.6V software adjustable, output fluctuations ≤ 1%.
Module power supply DC power supply, power ≥ 2800W
Temperature rise time From 20 ºC to 100 ºC <60min (empty box)
Noise ≤ 85dB (A) / 1m distance
Circulating wind Horizontal air supply, box circulation wind > 2 m / s, when the over-temperature alarm, circulating wind shall not stop.

FAQ

Q1 : Can you customize the product?

A: Yes, we can customize any products according to requirements. Hot selling lab electronic

temperature humidity cabinet/Environmental climate test chamber/Car Battery Safety Test Chamber also can be customized.

Q2 : How to choose the most suitable products?

A: Our professional team will give you the best suggestion, just be patiently to tell us the information

about the parameters you require.

Q3 : Can you arrange installations and commissioning in our lab?

A: Firstly, for standard chamber we had 3-5 days commissioning before shipping,

you just need link power in your lab, then you can start to operate.

Secondly, we had detailed operation manual with chamber , any problems you can find and solve in it.

Thirdly, some customized chambers we should install and teach your team to operate .
