Surveillance Mwir Cooled Infrared Thermal Security Camera Long Range with 600/137/22mm
Surveillance Mwir Cooled Infrared Thermal Security Camera Long Range with 600/137/22mm
Surveillance Mwir Cooled Infrared Thermal Security Camera Long Range with 600/137/22mm
Surveillance Mwir Cooled Infrared Thermal Security Camera Long Range with 600/137/22mm
Specifications
Brand Name :
JOHO
Model Number :
JH640-600/137/22
Certification :
CE; ISO9001;2000
Place of Origin :
Wuhan China
MOQ :
negotiation
Price :
negotiation
Delivery Time :
negotiation
Packaging Details :
Safety Box
Detection Ramge :
>15km (Vehicle); >10km (Human)
Detector :
Mwir Cooled Hgcdte Fpa
Pixel :
640X512
Focus Length :
600mm/137mm/22mm
Description
Surveillance Mwir Cooled Infrared Thermal Security Camera Long Range with 600/137/22mm


JH640-600/137/22 is especially designed for long range surveillance. Multiple field of view optics 600/137/22mm, it achieves the super long mission of fast situational awareness and target reorganization with the wonderful wide, medium and narrow Field of view in one system. It is definitely a very good choice for ground, coast and air defense EO system integrator.

Application:

  • Target detection and recognition in military industry
  • Public security
  • Boarder & coast defense
  • Industrial inspection



Range performace


Target
medium vehicle
human

Detection range
≥15km
≥10 km

Recognition range
≥10 km
≥5 km

Technical Data


Detector
Detector materials Cooled FPA HgCdTe
Pixels 640×512
Spectral range 3.7~4.8μ m
NETD ≤ 15 mK (F#4)
Cooling ≤ 8Min, Stirling
Optics
Lens 600mm/137mm/22mm (F#4)
FOV WFOV: 24.6° × 19.8°/MFOV: 4° × 3.2°/NFOV: 0.92° × 0.73°
Image presentation
Video output Analog PAL/NTSC; digital Cameralink
Frame frequency 25Hz, 50Hz (100Hz, 200Hz optional)
Brightness & contrast Auto/Manual
Polarity B& W, B& W inverse
Interfaces
Command and control RS232/ RS422 alternative
Interface Optional: Cameralink
Video output RCA/BNC alternative
Power System
Power supply 110/ 220VAC adapter
Environmental Parameters
Operating temperature -40° C to +60° C
Storage temperature -40° C to +60° C
Physical Characteristics
Weight 8.1kg (without housing)
