Specifications
Brand Name :
Wuhan Joho
Model Number :
JH602-1100
Certification :
ISO, SGS
Place of Origin :
China Wuhan
MOQ :
1pcs
Price :
negotiable
Supply Ability :
500pcs per year
Delivery Time :
4 month
Packaging Details :
standard packaging
Gyro Stabilised Gimbal :
2 axis
Sensor :
Cooled MWIR Thermal Imager
Lens :
110-1100mm continuous zoom lens
Application :
Long range suveillance
Thermal camera Detector Detector :
Cooled HgCdTe FPA
Weight :
approx. 127kg (Camera); 10kg(CDU)
Input voltage :
DC24V/15A, 220VAC
Communication :
RS422
Pixel :
640×512
Spectral Band :
3.7μm~4.8μm
Description

JH602-1100 Cooled MWIR Gyro Stabilizer Camera Tracking System

It is suitable for all kinds of motion carriers (such as aircraft, ships, ground equipment, etc.), and has the functions of target search, observation and tracking, aiming control, navigation and early warning.

Features

  1. High precision infrared thermal continuous zoom optical system and compound variable control system ensure clear image and stable axis in the range of 110mm ~ 1100.
  2. 640x512 cooled FPA HgCdTe detector
  3. Military grade parts, high reliability, long life.
  4. All sealed waterproof, optical mechanical and electrical integration design, strong anti vibration ability.
  5. The multi axis stable platform and high precision gyro servo control system are adopted to ensure the stable tracking accuracy of the system.

Functions

  1. Searching at target area
  2. Quick search and detect, recognize and distinguish at specific target
  3. Gyro stability augmentation function , insulating carrier disturbance, line of sight stablization
  4. Auto/manual tracking specific target
  5. Real-time output and display the image at the sight line area
  6. Turret can be controlled through the joystick or IPC
  7. System self-test
  8. Real-time reporting target position information (azimuth, elevation, distance, and angle speed,etc)

Technical Specifications

THERMAL CAMERA
Detector Cooled HgCdTe FPA
Pixel 640×512
Spectral band 3.7μm~4.8μm
FOV 0.5°×0.4°~5°×4° with 1100~1100mm continuous zoom lens
Optical-axis parallelism ≤1pixel
Electronic zoom 2× (optional: 4×)
SERVO
Stabilization accuracy ≤0.15mrad(1σ)
Turret direction range Azimuth: 0~330° (optional n×360°);
Elevation: -20°~+75°
Turret maximum angle speed Azimuth: >50°/s; Elevation: >50°/s
Tracking mode CTW, CTB, COT
Video signal format standard CCIR
Data rate 50Hz,100Hz
Communication RS422
POWER
Input voltage DC24V/15A, 220VAC
Consumption 96W (average); 240W (maximum)
ENVIRONMENTAL
Operating temperature range -40ºC~+60ºC
Storage temperature range -50ºC~+70ºC
PHYSICAL
Dimension 700mm × 700mm × 1050mm (system)
400mm × 300mm × 190mm (CDU)
Weight approx. 127kg (Camera); 10kg(CDU)
