Multi-Sensor Electro-Optical Infrared Tracking System With HgCdTe MVIR Cooled Thermal Camera
Multi-Sensor Electro-Optical Infrared Tracking System With HgCdTe MVIR Cooled Thermal Camera
Multi-Sensor Electro-Optical Infrared Tracking System With HgCdTe MVIR Cooled Thermal Camera
Multi-Sensor Electro-Optical Infrared Tracking System With HgCdTe MVIR Cooled Thermal Camera
Multi-Sensor Electro-Optical Infrared Tracking System With HgCdTe MVIR Cooled Thermal Camera
Multi-Sensor Electro-Optical Infrared Tracking System With HgCdTe MVIR Cooled Thermal Camera
Specifications
Brand Name :
JOHO
Model Number :
JH602-300/75
Certification :
ISO9001:2000
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T, L/C, D/P
Supply Ability :
100Sets/Year
Delivery Time :
6months
Packaging Details :
Aluminum Alloy Safety Case with vibration-proof, water-proof
Detector :
cooled HgCdTe FPA
Pixel :
320*256 ( optional 640*512 higher resolution)
Spectral Band :
3.7μm~4.8μm
Measurement accuracy :
≤ ± 5m
Communication :
RS422/RS232
Power Supply :
DC 24V/15A , DC28V/20A
Video Signal Format :
CCIR PAL standard B/W
FOV :
WFOV:7.3°× 5.8° NFOV: 1.8°× 1.4°
FOV Switching Time :
≤ 1s
Description

Shipborne EOS Multi Sensors Electro-Optical Infrared Tracking Camera System

Equipped with a high performance HgCdTe MVIR cooled thermal camera(optional 640×512),continuous zoom TV camera and laser range finder, JH602-300/75 is capable of search target at day/night, as well as recognition, tracking ranging and aiming target, real-time output target position and distance data for navigation and early warning.

Functions

  • Detection, identification and recording of ground and air targets day and night

  • Measuring Target Distance

  • Manual/automatic target tracking

  • Built-in self-test report self-test results

  • Report high precision target position (azimuth and elevation) and range data to CMS

  • Receiving target specified data from CMS

Applications

It is applied to different carriers (such as aircraft, ships and vehicles) to search, observe and track targets with collimation control, navigation and early warning functions.

Features

  • High precision calibration to ensure the integration of three sensors including IR,day light camera, LRF
  • Military qualified with high reliability and long lifetime, suitable for any harsh environment
  • Integrated fully sealed design with strong shock and vibration resistance
  • Built-in high accuracy gyro stabilization to isolate ship disturbance and stabilize LOS.
  • Highly integrated design with embedded control circuit and optimized system configuration

Technical specification

THERMAL CAMERA
Detector cooled HgCdTe FPA
Pixel 320*256 ( optional 640*512 higher resolution)
Spectral band 3.7μm~4.8μm
FOV WFOV:7.3°× 5.8° NFOV: 1.8°× 1.4°
FOV switching time ≤ 1s
Electronic zoom 2×
DAY LIGHT CAMERA
Detector 752*582, 1/3" white/black CCD
FOV 18°*13.5°~1°*0.75° continuous zoom
LASER RANGE FINDER
Wavelength 1.06μm
Ranging 300m~20km (visibility 23km, 15m*10m target)
Measurement accuracy ≤ ± 5m
SERVO
Stabilization accuracy ≤ 0.2mrad (1σ)
Turret direction range Azimuth: ± 160° (0°is bow direction); Pitch: -20°~+75°
TURRET
Azimuth ≥50°/s
Elevation ≥50°/s
Video signal format CCIR PAL standard B/W
Communication RS422/RS232
ENVIRONMENTAL
Operating temperature range -40℃ ~ +50℃
Storage temperature range -50℃ ~ +70℃
POWER
Power Supply DC 24V/15A, DC28V/20A
Power Consumption

DC24/96W (avg.)/240W (Max.)

DC28V/28W(avg.)/70W (Max.)
PHYSICAL
Dimension Turret ≤ Φ400× 750
Control box 500 mm X 230 mm X 87 mm
Turret Weight ≤ 120kg (including mobile base);
Control box Weight ≤ 5kg
