2-Axis Dual-Sensor Night Vision Airborne EO IR Tracking System With Small Size
2-Axis Dual-Sensor Night Vision Airborne EO IR Tracking System With Small Size
2-Axis Dual-Sensor Night Vision Airborne EO IR Tracking System With Small Size
2-Axis Dual-Sensor Night Vision Airborne EO IR Tracking System With Small Size
2-Axis Dual-Sensor Night Vision Airborne EO IR Tracking System With Small Size
2-Axis Dual-Sensor Night Vision Airborne EO IR Tracking System With Small Size
Specifications
Brand Name :
JOHO
Model Number :
JHP320-B220
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T, L/C,, Western Union, MoneyGram
Supply Ability :
50Sets/Year
Delivery Time :
negotiation
Packaging Details :
Standard Safety Equipment Case
Function :
Searching, Observation, Tracking and Positioning
Type :
Day Light Camera Sensor
Application :
Navigation, Surveillance, Rescue, Searching
Customized :
Support Customized
Platform :
Two-axis
Detector :
1/2.8" CMOS
Pixel :
1920x1080
Focal Length :
4.3mm~129mm (30x Optical Zoom)
Focus :
Auto/Semi-Auto/Manual
Communication :
RS232
Power Supply :
DC 12V
Description

2-axis Dual-sensor Night Vision Airborne EO/IR System

JHP320-B220 dual-sensor gimbal is applicable on UAV, small aircraft, aerostat and other airborne platforms for target surveillance, tracking and positioning. The system is an optical-mechanical-electrical integration, configured with 80mm uncooled thermal camera, 30×continuous zoom HD 1080p day light camera.

Features and Functions
1) Azimuth and elevation 2-axis stabilized platform, integrated with high accuracy gyro and servo control system, to realize full coverage reconnaissance, support both day and night observation.
2) Small size, light weight, and compact structure, strong carrier adaptability, low consumption, and high cost-effectiveness.
3) Video tracking capability with manual locking and tracking;
4) High accuracy calibration to ensure the alignment of thermal camera and daylight camera.
5) Capable of data return such as working mode, azimuth angle, elevation angle,etc.

Technical Specification
THERMAL CAMERA
Detector 640*512 Uncooled FPA
Spectral band 8μm~14μm
Pixel 17mm x 17mm
Focal length 80mm
DAY LIGHT CAMERA
Detector 1/2.8" CMOS
Focal length 4.3~129mm, 30x
Resolution 1920×1080
SERVO
Stabilization accuracy ≤0.5mrad(1σ)
Turret direction range Azimuth:360° continuous; Elevation:＋20°～－90° (Customizable)
TURRET MAXIMUM ANGLE SPEED
Azimuth ≥30°/s
Pitch ≥30°/s
INTERFACE
Video Out HDMI
Communication RS232
ENVIRONMENTAL
Operating temperature range -20℃ ~ +50℃
Storage temperature range -30℃ ~ +60℃
Tracking
Tracking speed ≥2.5FOV/S
Min tracking contrast ratio 5%
Dynamic tracking accuracy superior to 1mrad
POWER
Power Supply DC 12V
Power Consumption ≤120W (steady); ≤360W(peak)
PHYSICAL
Dimension Turret ≤ Φ240× 350mm
Turret Weight ≤ 10kg
Color Customizable
Performance (Theoretic Value under Johnson DRI)
Vehicle (2.3×2.3m) Human (1.7×0.5m)
Detection 5400m 1100m
Recognition 1800m 400m
Identification 900m 200m
