2'' Semiconductor Silicon Wafer Thickness 279μm
2'' Semiconductor Silicon Wafer Thickness 279μm
Specifications
Brand Name :
GaNova
Certification :
UKAS/ISO9001:2015
Place of Origin :
Suzhou China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
50000pcs/month
Delivery Time :
3-4 week days
Packaging Details :
Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.
Model Number :
JDCD06-001-002
Diameter :
2"
Orientation :
<1-0-0>,<1-1-1>,<1-1-0>
Type/Dopant :
P Type/Boron,N Type/Phos,N Type/As, N Type/Sb
Thickness(μm) :
279
Thickness Tolerance :
Standard ± 25μm,Maximum Capabilities ± 5μm
Resistivity :
0.001-100 ohm-cm
Surface Finished :
P/E,P/P,E/E,G/G
TTV(μm) :
Standard <10 μm,Maximum Capabilities<5 μm
Bow/Warp :
Standard <40 μm,Maximum Capabilities<20 μm
Particle :
<10@0.5μm; <10@0.3μm; <10@0.2μm;
Description

2-Inch Silicon Wafer Thickness(μm)279 Resistivity 0.001-100 Ohm-cm

2-Inch Silicon Wafer MEMS Devices, Integrated Circuits,Dedicated Substrates For Discrete Devices


Overview

Few of us have a chance to encounter an actual silicon wafer in daily life. This ultra-flat disk is polished to a mirror-like surface, and made as free as possible of tiny surface irregularities, making it the flattest object in the world. It is also ultra-clean, virtually free of microparticles and other impurities. These qualities are necessary so it can be used as the substrate material of today's state-of-the-art semiconductors.

Specification

silicon wafer

Diameter

 2"/3"/4"/5"/6"/8"/12"
Grade Prime
Growth Method CZ
Orientation <1-0-0>,<1-1-1>,<1-1-0>
Type/Dopant P Type/Boron,N Type/Phos,N Type/As, N Type/Sb
Thickness(μm) 279/380/525/625/675/725/775
Thickness Tolerance Standard ± 25μm,Maximum Capabilit/ies ± 5μm
Resistivity 0.001-100 ohm-cm
Surface Finished P/E,P/P,E/E,G/G
TTV(μm) Standard <10 μm,Maximum Capabilities<5 μm
Bow/Warp Standard <40 μm,Maximum Capabilities<20 μm
Particle <10@0.5μm; <10@0.3μm; <10@0.2μm;
