High Reliability High Voltage Indicators For Switchgear Electrical Inspection
High Reliability High Voltage Indicators For Switchgear Electrical Inspection
Specifications
Brand Name :
QIUPU
Model Number :
DXN-Q
Certification :
IEC
Place of Origin :
WENZHOU
MOQ :
100 PCS
Payment Terms :
T/T, Western Union
Supply Ability :
5000PCS/Month
Delivery Time :
5 Days
Packaging Details :
Cartons
Material :
Plastic
Rated Voltage :
3.6kV-40.5kV
Work Voltage :
AC/DC110V/220V
Rated Current :
16A
Color :
Black
Contact :
2K
Description

DXN-Q Indoor High Voltage Indicator with Switchgear equipment

In view of the problems existing in the old high-voltage electric display device, a new type of electric display device with high reliability, long life, no maintenance, clear and striking display can compensate the defect of the old high-voltage electric display device. The Beijing Power Supply Bureau has developed a new type of high voltage electric display and electric inspection device, which is used in conjunction with CG sensors, and can be used by means of electric display and on-site inspection to show whether the high voltage equipment has operating voltage and electric forced locking function.

The device solves many problems of neon lamp type electric display device. The old type of high-voltage electric display device with mandatory electrical latching, which is too simple in principle, consists of half wave rectifying and directly combining the signals from the A, B and C phase sensors to control the latching circuit. In this way, when the system has an anomaly of single phase grounding or absence phase, the drift of the locked-in control voltage can lead to the accident of the electrically connected grounding switch.

Item Technical data
Rated voltage (KV) 7.2 12 24 40.5
Rated frequency(Hz) 50
Insulator(capacity) insulating Frequency withstand voltage 5 min (KV) 25 32 42 68 100
Frequency withstand voltage 1 min (V) 2000
Lighting impulse withstand voltage (KV) 60 75 125 185
Rated Current 16A
Contact 2K
2K
