760mm × 99mm × 98mm Capacitor Induction Cross Flow Fan 220V / Industrial Motor
760mm × 99mm × 98mm Capacitor Induction Cross Flow Fan 220V / Industrial Motor
760mm × 99mm × 98mm Capacitor Induction Cross Flow Fan 220V / Industrial Motor
760mm × 99mm × 98mm Capacitor Induction Cross Flow Fan 220V / Industrial Motor
Specifications
Brand Name :
TOPFAN/ODM/OEM
Model Number :
MX60300CFWM22
Certification :
CE/ROHS/UL/SGS
Place of Origin :
China
MOQ :
500pcs
Price :
us$1.5/pcs to us$3.00/pcs, and negotiation
Payment Terms :
T/T or western Union
Supply Ability :
600,000pcs per month
Delivery Time :
5-12 working days after received your payment
Packaging Details :
carton
Voltage :
220-240V
Diameter :
98mm
Length :
760mm
Bearing type :
Ball Bearing
Frame Material :
Aluminum ADC-12
Blade Material :
Cast Iron
Description

760mm × 99mm × 98mm Capacitor Induction Cross Flow Fan 220V / Industrial Motor

1. Purpose:

It is applied in air cleaner,elevator,humidifier , laboratory,workshop,dehumidifier,projector and copy machine, etc..

2. Expeceed Life:

Ball Bearing 50,000 hours

3. ELECTRICAL CHARACTERISTICS:

ALL MEASUREMENTS PERFORMED AT25~30℃ ROOM TEMPERATURE

& 50~80%R.H.UNLESS OTHERWISE SECIFIED.

1

RATED VOLTAGE

VOLTS

V

220-240VAC

2

OPERATION VOLTAGE

VOLTS

V

160-242

3

FREQUENCY

Hz

Hz

50/60

4

NPUT CURRENT

AMP

A

0.10/0.13A±10%

AT RATED VOLTAGE

5

INPUT POWER

WATTS

W

28W ±10%

AT RATED VOLTAGE

6

ROTATION SPEED

RPM

RPM

1380/1610±10%

7

ACOUSTICAL NOISE(AVG)

dB(A)

dB(A)

≤43

DETAILS SEE ATTACHED PAGE.

8

MAX .AIR-FLOW

M³/H

Q

350/410

TWO-CHAMBER METHODS

DEAILS SEE ATTACHED PAGE.

9

MAX . AIR-PRESSURE

mmH2O

P

3.0

TWO-CHAMBER METHODS

DEAILS SEE ATTACHED PAGE.

10

INSULATION

RESISTANCE

MEG.

OHM

MΩ

＞20 MΩ

BETWEEN FRAME AND

TERMINAL

11

DIELECTRIC STRENGTH

1800V,3S,1MA

BETWEEN FRAME AND

TERMINAL.

12

ROTARY DIRECTION

CC W

13

INSULATION CLASS

CLASS E

14

LIFE EXPECTANC

15000 Hours at 25℃/65%RH

4. ENVIRONMENTAL:

4-1.OPERATING TEMPERATURE----------------------- -20 TO+50℃(CLASS E)

4-2.STORAGE TEMPERATURE ------------------------- -30 TO+75℃

4-3.OPERATING HOMIDITY-----------------------------------RH20%-80%

5. Specifications:

760mm × 99mm × 98mm Capacitor Induction Cross Flow Fan 220V / Industrial Motor

6: Dimensions (Unit:mm)


760mm × 99mm × 98mm Capacitor Induction Cross Flow Fan 220V / Industrial Motor
