San Ace High Speed Computer Case Cooling Fan 60 × 60 × 15 mm / High Air Flow Fan

San Ace High Speed Computer Case Cooling Fan 60 × 60 × 15 mm , are widely used in the computer information technology, network communications, as well as industrial production equipment, medical equipment, home appliances, etc.

Gemneral Specification:

Frame and Impeller: Frame: Plastic (Flammability: UL 94V-0), Impeller: Plastic (Flammability: UL 94V-1)
Expected life : See the table below. (L10 life: 90% survival rate for continuous operation in free air at 60˚C, rated voltage)
Motor protection function : Locked rotor burnout protection, Reverse polarity protection
Dielectric strength: 50/60 Hz, 500 VAC, for 1 minute (between lead wire conductors and frame)
Insulation resistance :10 MΩ or more with a 500 VDC megger (between lead wire conductors and frame)
Sound pressure level (SPL): At 1 m away from the air inlet
Storage temperature : -30 to +70˚C (Non-condensing)
Lead wire : Red Black or Blue Sensor Yellow
Mass : 90 g

Specifications:

The models listed below have ribs and pulse sensors. For models without ribs, append "1" to the end of model numbers

Electrical Specification:

Airflow - Static Pressure Characteristics

Dimensions (Unit:mm)

Reference Dimensions of Mounting Holes and Vent Opening (unit: mm)
