120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier
120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier
120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier
120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier
120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier
120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier
120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier
120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier
Specifications
Brand Name :
MX (topfanchina)
Model Number :
MX12025GBU4
Certification :
CE ROHS
Place of Origin :
shenzhen, China
MOQ :
100pcs ( support two times sample order)
Price :
$ 3.50- $ 6.99 or Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
30 , 000pcs per month
Delivery Time :
7 - 10 working days after received payment
Packaging Details :
Carton Box or Negotiable
Fan type :
centrifugal blower fan
Meterial :
Plastic frame and impeller
Rate voltage :
12V 24V 48V
Color :
black or white
Temperature Range :
-20°C~+70°C
Protection :
Impedance Protected
Expected life :
50000hours
Description

120mm dc centrifugal blower fan with high speed 4800rpm, 12V 24V 48V PET round fan used for air purifier

Fan Application:

it can be used for air cooler , fireplace, household air purifier, car air purifier, car seat, air purification, stove, kitchen equipment, refrigerator, electric cabinet ventilation and cooling and so on.

Normal Description:

Modle MX12025GBU4
Fan type Small centrifugal fan
Size 120 x 120 x 25 mm
Voltage 48V
Bearing type Ball bearing
Speed 4500RPM
Signal function PWM FG
Lead Wire Four wire, 300mm ± 10mm length
Material Plastic ( 94V - 0 ), PET

Thermal characteristics:

Operating temperature: -20 ° C to + 70 ° C / 65% (RH)
Storage temperature: -40 ° C to + 70 ° C / 65% (RH)

Standard environmental conditions: unless otherwise specified, the standard temperature is 20 ° C and the relative humidity is 65% (RH).
Temperature rise: the surface temperature rise does not exceed 25 ° C, the coil temperature does not exceed 55 ° C.

120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier

Warm Note:

If the below information has any pramater or data that can not meet your demands, pls feel free to contact me, we can customize the fan according to your different demands, thanks for your help.

Fan specification:

120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier

Other fan:

120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier

Factory show and Company information:

120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier Shenzhen Topfan Technology Development Co., Ltd. is a professional fan design and processing enterprises. founded in 1996 in Shenzhen China, It's a manufacturer on AC fan and DC brushless fans. Products support OEM, ODM and passedCE, RoHS certificated and good sellers both at home and abroad, the products mainly includs axial fans, cross flow fans (tangential fan), blower fans (centrifugal), being widely used in the information technology, network communications as well as industrial equipment, medical equipment, home appliances and others.
120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier

Factory Workshop:

120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier

120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier

Certification:

120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier

♦Welcome to contact me:

120mm DC Centrifugal Fan 4800rpm , 12V 24V 48V PET Round Fan For Air Purifier
