120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification
120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification
120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification
120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification
120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification
120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification
120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification
120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification
Specifications
Brand Name :
MX / OEM / ODM
Model Number :
MX12038ABL1
Certification :
CE, ROHS, UL
Place of Origin :
Guangdong, China
MOQ :
100pcs
Price :
us$0.99 / pcs to us$4.99 / pcs, and negotiation
Payment Terms :
T/T, paypal
Supply Ability :
600, 000pcs per month
Delivery Time :
5 - 7 working days after received your payment
Packaging Details :
carton, other can be customized
Product name :
12038, 120mm fan, dustproof fan, CPU fans, 2000rpm fans, DC 12v fan, 4.7inchfan, 120mm dc fan, Bitcoin fan
Rate Voltage :
12V 24V 48V
Speed :
2800RMP / can do more higher or lower
Bearing type :
sleeve / ball bearing
Motor :
Impedance Protected And Reverse Polarity Protected
Weight :
78g
Frame and impeller material :
PBT, plastic
Size :
120 mm x 120 mm x 38 mm ( 12038 )
Blade :
can do 5 blade / 7 blade / 9blade
Description

120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification

Application:

  • Ventilation Equipment & System
  • Heating Equipment & System
  • Air Conditioner
  • Refrigeration equipment
  • MDBS ( Mobile Data Base Station )
  • Telecom power supply station
  • LED sighnal
  • industry equipment
  • medical equipment ,homeappliances

Description :

Dc brushless Fan, fan 120mm x 120mm x 38mm, 12038, 120mm fan, dustproof fan, CPU fans, 2000rpm fans, DC 12v fan, 4.7inch fan, compact fans 120mm dc fan, Bitcoin fan, small fan, high speed fan, DC Motor Fan, high quality fan, Portable Fan, CPU Fan, Computer case fan, laptop fan, air cooler fan, PWM Fan, FG cooling fan, LED Digital signage, mini fridge fan, air cooler fan.

Size 120 x 120 x 38mm
Speed

High speed, Middle speed, Low speed
Material PET Frame and PET impeller
Blade number

5 blades, 7 blades, 9 blades optional
Voltage 12V DC , 24V DC , 36V, 48V DC optional
Bearing type Ball bearing or Sleeve bearing optional
Function wire PWM, FG, RD optional
Protection level Waterproof ip68, dumproof, explosion - proof , high temperature, dustproof and anti - corrosionare all can be satisfied.

120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification

Specification :

Model Bearing Type Rated Voltage Operating Voltage Input Current Input Power Speed Max Air Flow Max Static Pressure Noise Weight
Part No. B.S VDC VDC Amp Watt RPM CFM m3/min Inch-H2O pa dB-A g
MX12038AB(S)U1 B.S 12 7.0-13.8 1.50 18.00 4000 165.05 4.67 0.60 150.63 58.00 262.00
MX12038AB(S)H1 B.S 12 7.0-13.8 1.00 12.00 3500 144.21 4.08 0.50 124.25 53.00 262.00
MX12038AB(S)M1 B.S 12 7.0-13.8 0.60 7.20 3000 115.29 3.27 0.34 83.55 48.00 262.00
MX12038AB(S)L1 B.S 12 7.0-13.8 0.40 4.80 2500 101.85 2.88 0.26 64.63 40.00 262.00
MX12038AB(S)U2 B.S 24 14.0-27.6 1.00 24.00 4000 165.05 4.67 0.60 150.63 58.00 262.00
MX12038AB(S)H2 B.S 24 14.0-27.6 0.60 14.40 3500 144.21 4.08 0.50 124.25 53.00 262.00
MX12038AB(S)M2 B.S 24 14.0-27.6 0.40 9.60 3000 115.29 3.27 0.34 83.55 48.00 262.00
MX12038AB(S)L2 B.S 24 14.0-27.6 0.20 4.80 2500 101.85 2.88 0.26 64.63 40.00 262.00
MX12038AB(S)U4 B.S 48 28.0-56.0 0.60 28.80 4000 165.05 4.67 0.60 150.63 58.00 262.00
MX12038AB(S)H4 B.S 48 28.0-56.0 0.40 19.20 3500 144.21 4.08 0.50 124.25 53.00 262.00
MX12038AB(S)M4 B.S 48 28.0-56.0 0.20 9.60 3000 115.29 3.27 0.34 83.55 48.00 262.00
MX12038AB(S)L4 B.S 48 28.0-56.0 0.12 5.76 2500 101.85 2.88 0.26 64.63 40.00 262.00

Dimention (unit:mm) :

120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification

Fan performance curse :

120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification

Company profile:

shenzhen topfan is aprofessional fan design and processing enterprises. Shenzhen Topfan - China Development Technology Co., Ltd, and founded in 1996 in Shenzhen China, It's a professional manufacturer on DC brushless fans and AC fans. products support OEM,ODM and passed CE, RoHS certificated and good sellers both at home and abroad, including Europe, North America, Asia etc. The products, including axial fans, cross flow fans, blower fans, being widely used in the information technology, network communications as well as industrial equipment, medical equipment, home appliances and others.

120mm CPU dustproof Fan CPU Cooling Fan With CE ROHS UL Certification

CONTACT INFROMATION

ATTN: krystal

Phone / skype / wechat: +86 13128824029

Email: krystal @ topfanchina.cn
