2Cm middle speed Equipment Cooling Fans PBT sleeve 20mm X 20mm X 10mm
2Cm middle speed Equipment Cooling Fans PBT sleeve 20mm X 20mm X 10mm
2Cm middle speed Equipment Cooling Fans PBT sleeve 20mm X 20mm X 10mm
2Cm middle speed Equipment Cooling Fans PBT sleeve 20mm X 20mm X 10mm
Specifications
Brand Name :
MX
Model Number :
MX2010ASM1
Certification :
CE / ROHS
Place of Origin :
China
MOQ :
200 pcs
Price :
USD 0 . 9 - USD 2 . 9 or Negotiable
Payment Terms :
T / T
Supply Ability :
40 , 000pcs per month
Delivery Time :
7 - 10 working days after received payment
Packaging Details :
Carton Box or Negotiable
Part Name :
MX20 axial Series
Voltage :
12 V ( Customizable )
Power Consumption :
0 . 35 - 0 . 65 W ( Customizable )
Air Flow :
0 . 42 - 1 . 25 CFM ( Customizable)
Speed :
15000 - 20000 RPM ( Customizable )
Bearing Type :
Ball Bearing / sleeve bearing
Description

2Cm middle speed Equipment Cooling Fans PBT sleeve 20mm X 20mm X 10mm

12V 2cm lmiddle speed PBT sleeve and ball bearing low price 20mm X 20mm X 10mm

2Cm middle speed Equipment Cooling Fans PBT sleeve 20mm X 20mm X 10mm

Model Bearing Type Rated Voltage Operating Voltage Input Current Input Power Speed Max Air Flow Max Static Pressure Noise Weight
Part No. B.S VDC VDC Amp Watt RPM CFM m3/min Inch-H2O pa dB-A g
MX2010AB(S)H5 B.S 5 2.8-5.5 0.13 0.65 15000 1.25 0.04 0.14 35.01 27.00 5.00
MX2010AB(S)M5 B.S 5 2.8-5.5 0.10 0.50 10000 0.73 0.02 0.05 11.77 22.00 5.00
MX2010AB(S)L5 B.S 5 2.8-5.5 0.07 0.35 8000 0.42 0.01 0.04 8.73 21.00 5.00
MX2010AB(S)H1 B.S 12 7.0-13.8 0.07 0.84 20000 1.70 0.05 0.24 60.90 30.00 5.00
MX2010AB(S)M1 B.S 12 7.0-13.8 0.50 0.60 15000 1.25 0.04 0.14 35.01 27.00 5.00
MX2010AB(S)L1 B.S 12 7.0-13.8 0.03 0.36 10000 0.73 0.02 0.05 11.77 22.00 5.00

2Cm middle speed Equipment Cooling Fans PBT sleeve 20mm X 20mm X 10mm

Specifications : 20 * 20 * 10 mm axial fan

Model : 20MM axial fan

Brand : MX

Manufacturer : Shenzhen Topfan Technology Development Co ., Ltd .

Rated voltage : DC 2 . 4V 3 . 3V 5V

Operating voltage range : 2 - 3 . 3V 2 . 5 - 3 . 3V 4 - 5 . 6V

Rated current : see specification

Rated power : see specification

Bearing Category : SLEEVE / BALL

Rotating speed : see specification

Fan life : SLEEVE : 1 - 1 . 25 million hours BALL : 3 - 5 million hours

Fan Category : Axial Fan DC Fan Brushless Fan Miniature Fan

Blade rotation direction : From the blade direction , counterclockwise rotation

Frame material : PBT + 30 % glass fiber + flame retardant

Operating temperature : - 25 ℃ - 75 ℃

Resistance : 500 megohms or more

Wires : The corresponding wire can be configured according to customer requirements , the length of heart

Terminals : According to the specific requirements to add standard terminals , special terminals need to provide or negotiate with us

Optional additional signals : RD signal FD signal PWM signal

Additional protection functions : moisture - proof , waterproof IP55 IP68

Quality Certification : CE ROSH

2Cm middle speed Equipment Cooling Fans PBT sleeve 20mm X 20mm X 10mm

Packing : Special high - strength carton packaging

Features : Brushless DC Low - power low noise long life ultra-thin ultra-thin axial fan
