11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment
11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment
11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment
11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment
11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment
11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment
11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment
11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment
Specifications
Brand Name :
MX / OEM / ODM
Model Number :
MX28080ABH11
Certification :
CE, ROHS
Place of Origin :
Guangdong, China
MOQ :
100pcs
Price :
us$ 8 / pcs to us$ 20.00 / pcs, and negotiation
Payment Terms :
T/T, Western Union, paypal
Supply Ability :
600,000pcs per month
Delivery Time :
12 working days after received your payment
Packaging Details :
carton, other can be customized
Product name :
280*280*80mm AC Fan For Industiral , AC Motor Fan 220V 380V , Machine Fan
Rate Voltage :
220V, 110V, 380V, 120V, 240V,
Current :
0.12A
Speed :
2400 / 2650 RMP
Bearing type :
sleeve / ball bearing
Motor :
Impedance Protected And Reverse Polarity Protected
Max air flow :
1512CFM
Weight :
2800g
Frame and impeller material :
metal
Description

11 Inch Metal Blade 220v ac axial brushless cooling fan 280*280*80mm for industry enquipment

280*280*80mm ac fan , industiral fan , ac motor fan , 220V 380V , machine Fan

1.Material :

Framework : Aluminum ADC-12,Painted Black

Protection : Impedance Protected

2.Major Characteristic Parameters :

Bearing type : Ball / Sleeve

Rated Voltage : 110 / 120 / 220 / 240 / 380 / 420 V

Speed : 2400 / 2650 rpm

Air Flow : 1341 / 1512 CFM

Niose Level : 65 / 70 dB - A

3.Expected life :

ball bearing 50, 000 hours ( 40 °c )

sleeve bearing 30, 000 hours ( 40 °c )

4.Allowable ambient temperature range :

Operating Temperature : -20℃ ~ 85℃

Operating Humidity : 20% ~ 85%RH

Storage Temperature : -30℃ ~ 140℃

Storage Humidity : 20% ~ 95%RH

Specification :

Model Bearing Type Rated Voltage Freq. Current Amp Input Power Speed Max Air Flow Max Static Pressure Noise Level Weight
Part No. S B Y VDC Hz Amp Watt RPM CFM m3/min Inch-H2O dB-A g
MX28080ABL11 B 110/120 50/60 1.2 120 2400/2500 1341/1512 37.9/42.8 136.7/154.1 65/70 2800
MX28080ABL22 B 220/240 50/60 0.55 120 2400/2650 1341/1512 37.9/42.8 136.7/154.1 65/70 2800
MX28080ABL38 B 380/420 50/60 0.36 120 2400/2650 1341/1512 37.9/42.8 136.7/154.1 65/70 2800

Dimention :

11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment

11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment

11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment

11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment 11 Inch Metal Blade 220v axial AC Brushless Fan 280*280*80mm for industry enquipment

Company information:

Shenzhen topfan is a professional fan design and processing enterprises. founded in 1996 in Shenzhen China and professionally engaged in the R & D and production of AC and DC brushless fans for more than ten years. Products support OEM, ODM and passed CE, RoHS certificated, we have developed a full range of axial fans with sizes from 20mm to 280mm, blower fan, cross flow fan. and good sellers both at home and abroad, This products are widely used in communication, industrial control, medical equipment, home appliances, electronics, power supplies, automobiles enquipment.

Our Services :

1.Payment Term : Paypal, Western Union, T/T

2.Port of loading : shenzhen or hongkong Port
3.Discounts : offered based on order quantities
4.Delivery time : 3-15 days according to order quantities.

Sincerely welcome to contact me :

ATTN : Krystal

E-mail : krystal@topfanchina.cn

Tel : 0086-755-26070926

Skype/whatsapp/wechat: 0086 13128824029
