Silent 9 Inch AC Brushless Fan , equipment cooling fans 225mm x 225mm x 80mm
Silent 9 Inch AC Brushless Fan , equipment cooling fans 225mm x 225mm x 80mm
Silent 9 Inch AC Brushless Fan , equipment cooling fans 225mm x 225mm x 80mm
Silent 9 Inch AC Brushless Fan , equipment cooling fans 225mm x 225mm x 80mm
Specifications
Brand Name :
MX
Model Number :
MX22580ABH22
Certification :
CE ROHS UL
Place of Origin :
GuangDong / China
MOQ :
500pcs
Price :
USD + 5 / 15 + Piece
Payment Terms :
T/T, Western Union
Supply Ability :
100000 + Piece + A Week
Delivery Time :
7 / 10 Working Days
Packaging Details :
Carton Box
Color :
Black
Bearing type :
Ball bearing
Size :
225mm x 225mm x 80mm
Air Volume :
618/760CFM
Blade Material :
Stainless Steel
Speed :
2500/2850RPM
Electric Current Type :
AC
Mounting :
Cooling fan
Description

Silent 9 Inch 225mm x 225mm x 80mm AC Cooling Fan / Brushless Computer Fan

Specifications :

Size(mm) Model Beaing system Rated voltage (v) Freq(HZ) Current amp (Amp) Rated Input Power Watt Speed (rpm) Air Flow(CFM) Air Flow (m3/mim) Max Static Pressure (Inch-H2o) Noise Leve (dB-A) Weight (g)
225*225*80 MX22580ABH11 Ball 110/120 50/60 0.74 80 2500/2850 618/760 17.5/21.5 2.48/3.05 63/66 2150
MX22580ABH22 Ball 220/240 50/60 0.40 80 2500/2850 618/760 17.5/21.5 2.48/3.05 63/66 2150
MX22580ABH38 Ball 380/420 50/60 0.32 80 2500/2850 618/760 17.5/21.5 2.48/3.05 63/66 2150
MX22580ABH38ø Ball 380/420 50/60 0.28 80 2500/2850 618/760 17.5/21.5 2.48/3.05 63/66

2150

Specifications

1 . we supply ac cooling fan ,
2 . motor protection ,
3 . low noise and long life expectancy ,
4 . ISO9000 , UL , CE , RoHS , TUV approved

General Specifications :

Frame

Aluminum Alloy

Impeller

Iron leaf

Temperature range

- 20°c - 105°c

Protection

Impedance Protected

Silent 9 Inch AC Brushless Fan , equipment cooling fans 225mm x 225mm x 80mmSilent 9 Inch AC Brushless Fan , equipment cooling fans 225mm x 225mm x 80mm

Silent 9 Inch AC Brushless Fan , equipment cooling fans 225mm x 225mm x 80mm

Silent 9 Inch AC Brushless Fan , equipment cooling fans 225mm x 225mm x 80mm

Silent 9 Inch AC Brushless Fan , equipment cooling fans 225mm x 225mm x 80mm

Additional protection functions can be added: AS automatic lock / start function, slow start function, over current protection, motor lock current protection, reverse connection protection, over voltage protection, PWM,FG,RD,Reversible fan,Waterproof fan, IP55, IP68

Quality certification: CE ROSH

Packing: special high-strength carton packaging

List of optional additional functions:

Moisture-proof: After moisture-proof treatment, it can work in the environment with humidity of 205-40%

Waterproof: up to IP68, under this level can be completely put into the water

Fire protection: all raw materials used can be made of flame retardant materials, with a maximum resistance of 75 ℃

  1. Our cooling fan has the following advantages :
    - fan with large air volume , low noise , long life ,( according to your requirements ) fire , water , corrosion-resistant and so on .
    - We have a strong design capability , according to customer requirements design and manufacture of special fan .
    - We understand the specific needs of fans in various industries and provide you with a variety of standard products to choose from .
    - Our fans using high-quality bearings , silicon steel , enameled wire , with higher reliability .
    - We provide thoughtful and meticulous service , as well as fast on-time delivery .

    1. We can design and develop customized product.
    2. We are able to research best solutions for customers if needed
