AC 220V Fridge Cooling Fan Industrial Ventilation Fans with Silicon steel Stator
AC 220V Fridge Cooling Fan Industrial Ventilation Fans with Silicon steel Stator
AC 220V Fridge Cooling Fan Industrial Ventilation Fans with Silicon steel Stator
AC 220V Fridge Cooling Fan Industrial Ventilation Fans with Silicon steel Stator
Specifications
Brand Name :
TOPFAN/ODM/OEM
Model Number :
MX8038ABH22
Certification :
CE/ROHS
Place of Origin :
China
MOQ :
500pcs
Price :
US$3 - 5
Payment Terms :
T/T, Western Union
Supply Ability :
600,000pcs per month
Delivery Time :
5-12 working days after received your payment
Packaging Details :
carton
Product Name :
AC Cooling Fan
Voltage :
110V / 220V
Frame :
Aluminum
Impeller :
Plastic
Bearing type :
Ball Bearing/Sleeve bearing
Motor :
Impedance Protected
Speed :
2300 / 2800 RPM
Size :
80x80x38mm(3.2*3.2*1.5Inch)
Description

220V Industrial Ventilation Fans / 80x80x38mm Cooling Fan , AC Cooling Fan

220V 80x80x38mm AC Industrial Ventilation Fan, long life expectancy and low noise , are widely used in network communications, as well as industrial production equipment, medical equipment, home appliances, etc.

Description:

  • 220V AC FAN,used for cooling and ventilation.
  • Frame:Aluminum ADC-12,Painted Black
  • Impeller:Plastic With 7 Blades
  • Stator& Rotor:Silicon steel
  • Magnet Wires:Copper 1 PEW
  • Bobbin:PA-66 UL 94 V-0
  • Bearing Type:Ball Bearing

Specification

Model

MX8038ABH22

Outline Dimension

080*80*38mm

Rated Voltage

AC 220V

Voltage Range

AC 200V~240V

Frequency

50/60Hz

Rated Current

0.09/0.07A±10%

Power Consumption

15/10W±10%

Speed

2300/2800RPM±10%

Max. Air flow

26/33CFM±10%

Max. Static Pressure

0.11/0.17Inch-H2O

Noise Level

31/35dB(A)

Weight

290g

Dielectric Strength

1800V/0.5mA/3s

Temperature Test of Run

t=<70K

Locked Rotor Protection

t=<130K

Environmental Specification

Operating Temperature:-20℃~85℃

Operating Humidity:20%~85%RH

Storage Temperature:-30℃~140℃

Storage Humidity:20%~95%RH
