13.8 Inch Small AC Fans / 350mm 380V AC Motor Fan / AC Exhaust Fan
13.8 Inch Small AC Fans / 350mm 380V AC Motor Fan / AC Exhaust Fan
13.8 Inch Small AC Fans / 350mm 380V AC Motor Fan / AC Exhaust Fan
13.8 Inch Small AC Fans / 350mm 380V AC Motor Fan / AC Exhaust Fan
13.8 Inch Small AC Fans / 350mm 380V AC Motor Fan / AC Exhaust Fan
13.8 Inch Small AC Fans / 350mm 380V AC Motor Fan / AC Exhaust Fan
13.8 Inch Small AC Fans / 350mm 380V AC Motor Fan / AC Exhaust Fan
13.8 Inch Small AC Fans / 350mm 380V AC Motor Fan / AC Exhaust Fan
Specifications
Brand Name :
MX,ODM,OEM
Model Number :
MX3505ABH38
Certification :
CE/ROHS/UL
Place of Origin :
China
MOQ :
500pcs
Price :
negotiation
Payment Terms :
T/T or western Union
Supply Ability :
40,000pcs per month
Delivery Time :
7-10 working days after received your payment
Packaging Details :
carton box
Voltage :
220V - 380V
Frequency :
50/60hz
Power Consumption :
135-170 W
Speed :
1360/1500R/Min
Color :
Black
Material :
Metal
Description

13.8 Inch AC Brushless Fan / 350mm 380V AC Motor Fan / AC Exhaust Fan


Applications:


Topfan’s 350mm AC fan products are utilized by all type of machines which required heat reduction systems, such as computer information technology, network communications, as well as industrial production equipment, medical equipment, home appliances, etc.


Description:

  • 220V , 380V AC FAN, used for cooling and ventilation.
  • Frame: Aluminum, Painted Black
  • Blade:metal
  • Stator& Rotor: Silicon steel
  • Magnet Wires: Copper 1 PEW
  • Bobbin: PA-66 UL 94 V-0
  • Bearing Type: Ball Bearing

Specification:

1. Size(mm): 350 × 50mm Round Fan
2. Model: MX3505ABH38
3. Rated voltage (v) : 220V, 380V
4. Current amp (Amp): 0.60/0.83A
5. Rated Input Power (Watt): 135/190
6. Speed : 1360/1500R/Min
7. Max air Flow: 2670/2900m³/h
8. Noise Leve (dB-A):58/60
11. Weight (KG): 5.0KG

Safety Approvals:

Safety Approvals

File No

Safety Approvals

File No

UL

N/A

RoHS-TUV

N/A

CUL

N/A

CCC

N/A

TUV

N/A

CE

N/A

TUV-GS

N/A

C-Tick

N/A

Environmental Specification:

Item

Specification/Condition

01

Operating Temp. Range

Temperature:-20℃~75℃
Humidity:20%~85%RH

02

Storage Temperature

Temperature:-30℃~140℃
Humidity:20%~95%RH

03

Life

50000H



Main Materials/Parts Specification:

(Item

Specification

01

Blade

(PBT) PBT+15%GF

02

Frame

Aluminum ADC-12,Painted Black

03

Stator& Rotor

Silicon stee

04

Magnet Wires

Copper 2 UEW

05

Bobbin

PA-66 UL 94 V-0




Dimension:

13.8 Inch Small AC Fans / 350mm 380V AC Motor Fan / AC Exhaust Fan



About Our Company

1. As a professional manufacturer, we specialize in Brushless DC&AC cooling fans and CPU coolers for over 10 years.

2. Our products are extensively applied to all kinds of refrigeration equipments, air conditioner, cooling and ventilation instruments.

3. Customized design is available.

4. OEM &ODM service are welcome.

5.Factory qualification with CE,UL,ROHS,FCC,TUV.

How to Select a right cooling fan?


A: Where are you used? Application for what?
B: What's size limitation do you have?
C: What's voltage do you require (5V DC,12/24V DC, 85V-125V ,190V-250V)?
D: What's power or CFM airflow required?
It will help us to give you good idea to quote
