Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm
Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm
Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm
Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm
Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm
Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm
Specifications
Brand Name :
MX
Model Number :
MX28080ABH22
Certification :
CE ROHS UL
Place of Origin :
GuangDong / China
MOQ :
500 pcs
Price :
USD + 5 / 15 +Piece
Payment Terms :
T/T, Western Union
Supply Ability :
100000 + Piece + A Week
Delivery Time :
7 - 10 Working Days
Packaging Details :
Carton box, we can also packing it according to customer requirements
Frame :
aluminum
Size :
280mm x 280mm x 80mm
Bearing type :
ball bearing
Voltage :
220 / 240v , 110 - 120 V , 220 - 240 V , 380 V - 420V
Power :
120w
Max. Static Pressure :
136 . 7 / 154 . 1INCH - H2O
Blade Material :
Stainless Steel
Electric Current Type :
AC
Description

Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm

280×280×80mm AC fan, low noise and long life expectancy, are widely used in network communications, as well as industrial production equipment, medical equipment, home appliances, etc.

Description :

220V AC FAN 280mm ,used for cooling and ventilation.

Frame: Aluminum ADC-12,Painted Black

Blade : metal

Stator & Rotor : Silicon steel

Magnet Wires : Copper 1 PEW

Bobbin : PA-66 UL 94 V-0

Bearing Type : Ball Bearing

Packaging Detail : white/color box, blister package

Life Expectancy : Dual Ball Bearing: 50000 hours

Sleeve Bearing : 20000-25000 hours

Standard : Fully CE , ROHS Approved

Specification :

Model

MX28080ABH22

Outline Dimension

280*280*80mm

Rated Voltage

AC 220V

Voltage Range

AC 220V~240V

Frequency

50/60Hz

Rated Current

1.2A±10%

Power Consumption

120W±10%

Speed

2500RPM±10%

Max. Air flow

1512CFM±10%

Max. Static Pressure

154Inch-H2O

Noise Level

70dB(A)

Weight

2800g

Dielectric Strength

1800V/0.5mA/3s

Temperature Test of Run

t=<70K

Locked Rotor Protection

t=<130K

Environmental Specification

Operating Temperature:-20℃~85℃

Operating Humidity:20%~85%RH

Storage Temperature:-30℃~140℃

Storage Humidity:20%~95%RH

Model Bearing Type Rated Voltage Freq. Current Amp Input Power Speed Max Air Flow Max Static Pressure Noise Level Weight
Part No. S B Y VDC Hz Amp Watt RPM CFM m3/min Inch-H2O dB-A g
MX28080ABL11 B 110/120 50/60 1.2 120 2400/2500 1341/1512 37.9/42.8 136.7/154.1 65/70 2800
MX28080ABL22 B 220/240 50/60 0.55 120 2400/2650 1341/1512 37.9/42.8 136.7/154.1 65/70 2800
MX28080ABL38 B 380/420 50/60 0.36 120 2400/2650 1341/1512 37.9/42.8 136.7/154.1 65/70 2800

Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm

Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm

Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm

Home Painted Black 220V AC Brushless Fan 11 Inch Motor 280×280×80mm

1. Samples delivory

2. very time is 7 working days . (2-3 samples of some conventional fans can be provided .)

3. Fans quantity : 1K - 5K , the delivery time is 7-10 working days ;

4. Fans quantity : over 5K , the delivery time is 15-20working days .

5. Depending on the different type of fan and quantity, there will be different delivery dates, please ask Mona for details .

6. International express:UPS/DHL/FEDEX and so on
