Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM
Specifications
Brand Name :
MX
Model Number :
MX5010AB ( S ) M2
Certification :
CE / ROHS / UL
Place of Origin :
ShenZhen / China
MOQ :
500 pieces
Price :
USD + 1 TO 5 + Pieces
Payment Terms :
T/T, Western Union
Supply Ability :
70000 + Pieces + A Week
Delivery Time :
5 - 8 Working Days
Packaging Details :
Carton Box
Current Amp :
5V 12V 24V 48V
Fan size :
6010 6015 6020 6025 6038 7010 7015 7020 7025 8010 8015 8020 8025 8032 8038 9225 9232 9238
Speed :
2000 / 8000 RPM
Bearing Type :
Sleeve Bearing & Ball Bearing
Frame :
Plastic
Impeller :
Plastic
Description

Brushless Axial DC Fan 12v 24V , High Air Flow Fans With 2000 / 8000RPM

  • Voltage : 5V , 12V , 24V, 48V

  • Insulation Resistance : 10M AT 500VDC

  • Dielectric Withstand : Between lead or terminal and housing 700VAC for 3 secretary or 500 VDC for 1Min

  • Opetation Temperature : - 10℃ ～ 70℃ ( Ordinary humidity )

  • Storage Temperature : - 40℃ ～ 70℃ ( Ordinary humidity )

  • Life Expectancy : Ambient temperature 25℃ and humidity 65 %

Ball bearing : 50 , 000Hours

Sleeve bearing : 30 , 000Hours

Brushless axial dc fan 60mm , 70mm , 80mm , 90mm, low noise and long life expectancy, are widely used in the computer information technology, network communications, as well as industrial production equipment, medical equipment, home appliances, etc.

● Brushless DC Fan, Axial DC Fan, DC Motor Fan,CPU Fan, Computer case fan, laptop fan, PWM Fan, FG cooling fan, LED Digital signage
● Various Size
● High speed , Middle speed, Low speed
● Plastic Frame or Die-Cast Aluminum Frame and Plastic impeller
● 5 blades 7 blades or 9 blades
● 5V DC 12V DC 24V DC or 48V DC
● Ball bearing or Sleeve bearing or Hydraulic bearing
● Terminal or Lead wire
● Waterproof explosion proof or high proof are can be satisfied.

Bearing System

Test Temperature

Test time

Sleeve Bearing

25℃

30000

Sleeve Bearing

40℃

25000

Sleeve Bearing

60℃

20000

Bearing System

Test Temperature

Test time

Ball Bearing

25℃

50000

Ball Bearing

40℃

45000

Ball Bearing

60℃

38000
