Anti Corrosive Coating API 5L X60 X65 PSL1 ERW Line Pipe
Anti Corrosive Coating API 5L X60 X65 PSL1 ERW Line Pipe
Specifications
Brand Name :
HuaYang steel pipe
Model Number :
114.3-610mm
Certification :
API CE ISO
Place of Origin :
China
MOQ :
10tons
Price :
600-800USD
Supply Ability :
100000tons per month
Delivery Time :
30days
color :
black
material :
70X
end :
bevel
OD :
219
WT :
12.7
length :
12m
coating :
3PE
transport :
shipment
deliver time :
30days
function :
transmission
Description

Anti Corrosive Coating API 5L X60 X65 PSL1 ERW Line Pipe

Electric resistance welded (ERW) pipe is manufactured by cold-forming a sheet of steel into a cylindrical shape.Current is then passed between the two edges of the steel to heat the steel to a point at which the edges are forced together to form a bond without the use of welding filler material.Initially this manufacturing process used low frequency A.C. current to heat the edges. This low frequency process was used from the 1920’s until 1970. In 1970, the low frequency process was superseded by a high frequency ERW process which produced a higher quality weld. Over time, the welds of low frequency ERW pipe was found to be susceptible to selective seam corrosion, hook cracks, and inadequate bonding of the seams, so low frequency ERW is no longer used to manufacture pipe. The high frequency process is still being used to manufacture pipe for use in new pipeline construction.

Pipe Type: ERW Pipe,ERW Steel Pipe,Electric Resistance Welding Pipe

Application: Oil/Gas/Water transmission,Machinery Manufacturing

Specification: Outer diameter:114.3mm-660mm

Wall thickness: 6.35mm-20mm

LENGTH:5.8/6/11.8/12 meters

Standard & Grade:API 5L:Gr.A,Gr.B,X42,X46,X52,X56,X60,X65 PSL1 and PSL2

ASTM A53:Gr.A,Gr.B

End: Square Ends/Plain Ends (straight cut, saw cut, torch cut),Beveled/Threaded Ends

Surface:Black Painting/Oil Painting/Anti-Rust oil/Anti-Corrosive Coating

Packing: Bundled,Plastic Caps Plugged,Waterproof Paper/Bag Wrapped

Product Name ERW Mild Steel Gi galvanized Pipe and tube
Steel Grade X70
Standard API 5L
Surface Coating

Hot dip galvanized zinc coating 30um or above

Painted black or red
Pipe Ends Plain ends or Threaded ends or Grooved ends or Beveled ends
Certificates ISO 9001 / ISO 18001 / ISO 14001
Trade terms FOB, CFR, CIF, EXW, FCA
Payment terms T/T, LC
Delivery time 35-50 days (based on quantity) after receiving advanced payment by T/T or LC .
Main market Southeast Asia, South Asia, Middle East, Europe, Middle&South America, Africa and Oceania

Anti Corrosive Coating API 5L X60 X65 PSL1 ERW Line Pipe
