Specifications
Brand Name :
TENGTIAN
Model Number :
3 X 1500
Certification :
CE ISO9000 BV
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
4 set/year
Delivery Time :
120 working days
Packaging Details :
standard export package
Production Name :
3x1500mm Carbon Steel Sheet Slitting Machine Production Line With CE ISO9000 BV
model :
3 X 1500
Feature :
Directly and Stable
Max size :
3 X 1500 mm
Thickness :
0.5 - 3 mm
Cutting Length :
1500 m
Warranty :
one year
Key words :
Steel Sheet Slitting Machine Production Line With CE ISO9000 BV
Description

3x1500mm Carbon Steel Sheet Slitting Machine Production Line With CE ISO9000 BV

1. 3x1500mm Carbon Steel Sheet Slitting Machine Production Line With CE ISO9000 BV General Introduction

This production line is suitable for continuous longitudinal shearing strips with a width of 800- 1500mm and a thickness of 0.5-3mm for hot-rolled ordinary carbon structural steel, low-alloy structural steel and other materials. Referred to as 1500 × 0.5 ~ 3mm slitting unit.

2. 3x1500mm Carbon Steel Sheet Slitting Machine Production Line Main Parameters and Specifications:

1) Material Specifications:

Raw Material Hot rolled steel coil, material Q235B,Cold-rolled steel plate, galvanized sheet, etc
Outer diameter of steel coil Φ800-1800mm
Inner diameter of steel coil Φ508mm-610mm
Coil width 800- 1500mm
Steel strip thickness 0.5-3.0mm
Coil Weight Max25 tons

2) Finished Product:

Inner diameter of steel coil Φ508-610mm
Outer diameter of steel coil Φ800-1800mm
Coil weight Max25 tons
Unit Speed: Drawing shear: 10-50m/min (thickness≤5mm)

3.3x1500mm Carbon Steel Sheet Slitting Machine Production Line Process

coil preparation 一loading car 一 uncoiler 一 straight head 一 centering vertical roller 一pinch leveler 一cross cutter 一 centering vertical roller 一 disc Shear 一 edge rewinder 一transition table一 steel belt separation feeding device一recoiler一unloading coil

4.Formal Equipment composition

No. Name
1 coil preparation table
2 loading car
3 uncoiler
4 straight head and pinch leveler
5 cross cutter
6 centering vertical roller
7 disc Shear
8 edge rewinder
9 transition table
10 feeding device
11 recoiler
12 unloading car
13 hydraulic system
14 electronic control system

Packaging and transportation of equipment:

Packaging of equipment: All electric control cabinets, consoles, instruments, spare parts, etc. are packed in wooden boxes, and the cost shall be borne by the supplier. The machinery and equipment are naked, and waterproof and rust-proof measures are added during transportation.

Transportation of equipment: The transportation cost shall be borne by the buyer. ⑵Equipment installation and debugging:

A) The installation of the equipment shall be carried out by the purchaser, and the supplier shall be responsible for the guidance.

B) The supplier provides technical guidance for installation and commissioning.

C) The installation and commissioning time is about 25 days.

Quality Commitment and Service

1. Equipment warranty for one year, long-term maintenance.

2. Provide general assembly drawing, foundation drawing, piping layout drawing, electrical schematic drawing, wearing parts drawing and other necessary drawings of the equipment.

3. The company has a full-time technical service team, mainly composed of engineers and technicians. After receiving the user's notification, we can give an immediate reply, and send someone to the user's site for after-sales service at any time.
