Specifications
Brand Name :
TENGTIAN
Model Number :
200 x 200 x 8 mm
Certification :
CE ISO9000 BV
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5 set/month
Delivery Time :
60 wording days
Packaging Details :
standard export package
Production Name :
Tube Mill Machine
Model :
HG 200
Feature :
high quality and high precision
Other pipe :
square pipe and Rectangular pipe
Max size :
100 x 100 - 200 x 200 mm
Thickness :
2 . 0 - 8 . 0 mm
Length :
6 - 12 m
Rollers :
include
Power(w) :
1000kw
Key words :
Square Pipe Milling Machine Tube Mill Machine
Description

High Quality 200 X 200 X 8 Mm Square Pipe Milling Machine Tube Mill Machine

1.Machine General Introduction

200 X 200 X 8 mm square tube mill fast speed for welded square tube mill is designed to produce welded round pipes100 x 100 - 200 x 200 mm in diameter and 2 . 0 - 8 . 0 mm in wall thickness. Adopting roll pass design, the production line can manufacture welded steel pipes with good quality machining and high precision assembling.

2.Main Parameters and Specifications

(1)Material Specifications:
Standard Conforming to the YB189 - 64 standard
Material Low carbon steel and low alloy constructional steel
Mechanical properties δs ≤ 345 Mpa δb ≤ 610 Mpa
Strip Width 400 - 800 mm
Strip Thickness: 2 . 0 - 8 . 0 mm
Inner Diameter of Coils φ 480 ～ φ 570 mm
Outer Diameter of Coils φ 1000 ～ φ 1800 mm
Coil Weight ≤ 18 T
(2)Pipe Specification
Pipe Diameter

Square pipe:100 x 100 - 200 x 200 mm

Same size Rec. pipe

Thickness:2 . 0 - 8 . 0 mm
Length 6 -12 m
Pipe - cutting Precision 0 - 6 mm
Forming Speed 10 - 50 m/min
(3)The buyer should self - supply
Work shop 60 x 6 m , H ＞ 5m(crane to ground)
Power Approx 1212 KW 380V / 50 Hz / 3 phases
Circulation Cooling Water(whole system)

Flow: 20 T / h ～ 30 T / h

Pool Volume: 30 m 3

Compressed Air

(whole system)

Flow: 5 m / min

Pressure: 5 - 7 kg / cm2
Others Seller will supply list

3.Working Process:

strip steel to coil→uncoiler →end straightener→flattener→shear welder→storage material unit →formed,welding,cooling,accurate pipe Dia. size →accurate pipe length size,cutting→inspection →package

4.Quality and After-sale Service Warranty

Equipment arriving at the buyer, the technical services personnel at the scene debugging, maintenance, equipment commissioning, commissioning, operation and maintenance instruction, responsible for technical training for equipment operation and maintenance personnel of the buyer. Used in users abide by the rules, under normal operating equipment, since 12 months from the date of the arrival of the equipment, such as positively impact on the quality to use, parts damage lead to equipment can't normal work, factory will give the repair or replacement free of charge.
