Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic
Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic
Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic
Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic
Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic
Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic
Specifications
Brand Name :
TENGTIAN
Model Number :
114
Certification :
CE ISO9000 BV
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
5 set/year
Delivery Time :
100 working days
Packaging Details :
standard export package
Name :
Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic
model :
114
Feature :
high precision
Other pipe :
round,square pipe and rectangular pipe
Max size :
76 - 114 mm
Thickness :
1 . 5 - 4 . 0 mm
Cutting length :
4 - 6 m
Warranty :
one year
Key words :
Full Automatic Tube Mill / Tube Rolling Mill
Description

Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic

I.High Accuracy Large Diameter Full Automatic Tube Mill / Tube Rolling Mill Introduction

Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic is designed to produce welded pipes of φ 76 - φ 114 . 3 mm in diameter and 1 . 5 - 4 . 0 mm in wall thickness and same size of square pipe . Adopting roll pass design, the production line can manufacture welded steel pipes with good quality machining and high precision assembling.

Round pipe size: 76 - 114 mm Pipe thickness: 1 . 5 - 4 . 0 mm

II.High Accuracy Large Diameter Full Automatic Tube Mill / Tube Rolling Mill Main Parameters and Specifications:

Pipe material

Low carbon steel and low alloy constructional steel

OD of coil

φ 1000 ～ φ 1600 mm

ID of coil

φ 480 ～ φ 510 mm

Width of strip

160 ～ 320 mm

Thickness of strip

1 . 5 ～ 4 . 0 mm

Weight of strip

≤ 5 T

Welding thickness

1 . 5 - 4 . 0 mm

Cutting length

4 - 6 m

Pipe-cutting Precision

0～3 mm

Forming speed

20 - 60 m / min

III.Tube Rolling Mill Other Model

Model Diameter Range Pipe Thickness Line Speed(m/min)
HG20 8-25.4MM 0.3-1.2MM 120
HG32 10-32MM 1.4-1.5MM 120
HG50 16-76MM 0.7-2.5MM 30-120
HG76 25-76MM 1-4MM 30-100
HG89 32-89MM 1-4.5MM 30-80
HG114 45-114MM 1.5-5.0MM 30-60
HG165 60-165MM 3-7MM 30-50
HG219 114-219MM 4-8MM 20-40
HG273 114-273MM 4-10MM 15-30
HG325 165-325MM 4-10MM 10-30
HG426 165-426MM 4-12.7MM 8-25
HG508 219-508MM 4-16MM 8-20

IV.Quality and After-sale Service Warranty

1)Welded pipe forming machine is used to produce building materials pipe, which is widely used for building material , drain and energy supply pipe.Building and decoration profiles , extruded profiles , building profiles ,cold bending profiles , etc.
2)The carbon steel pipe diameter can be customized from 25-606mm with wall thickness 0.5- 25mm for different kinds of application.

3)We can customized the machine as per your requirements, the suitable steel strip width can be from 100mm to 1000mm, and we can also designed as per your drawing.
4)We will supply all the operation manual and video clip going with machine, and we supply free training here in our plant. Also we can send technicians to your site for installation and training, but the relevant should be borne by your company.

equipment arriving at the buyer, the technical services personnel at the scene debugging, maintenance, equipment commissioning, operation and maintenance instruction, responsible for technical training for equipment operation and maintenance personnel of the buyer. Used in users abide by the rules, under normal operating equipment, since 12 months from the date of the arrival of the equipment, such as positively impact on the quality to use, parts damage lead to equipment can't normal work, factory will give the repair or replacement free of charge.

Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic

Large Diameter 76-114mm Automatic Tube Milll High Accuracy Full Automatic
