350mm Api High Frequency Welding Tube Mill Machine
350mm Api High Frequency Welding Tube Mill Machine
350mm Api High Frequency Welding Tube Mill Machine
350mm Api High Frequency Welding Tube Mill Machine
350mm Api High Frequency Welding Tube Mill Machine
350mm Api High Frequency Welding Tube Mill Machine
Specifications
Brand Name :
TENGTIAN
Model Number :
350mm
Certification :
CE ISO9000 BV
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5 set/month
Delivery Time :
90 wording days
Packaging Details :
standard export package
Machine Name :
Tube Mill Machine
Product :
Round pipe and square pipe
Feature :
PLC control
material :
carbon steel
Other pipe :
round pipe
Max size :
350mm
Thickness :
8mm
Length :
6-12m
Rollers :
include
Model :
350
Key words :
Tube mill machine
Description

350mm API Hifrequency Welded Tube Mill Machine

Machine General Introduction

This tube mill machine is designed to produce welded steel pipes ,API round pipe.
Adopting roll pass design, the production line can manufacture welded steel pipes with good quality machining and high precision assembling.
this high precision high frequency welded pipe production line is mainly to product the Round pipe size φ180-350mm,thickness is from 3-8mm.This production line each unit equipment, full use of the domestic and foreign similar equipment, innovative design, full control with PC or computer control, advanced technology, convenient operation and maintenance, and reached the international level in the early ninety s, for the domestic leading level.

Main Parameters and Specifications

(1)Material Specifications:

Standard

Internatioanl standard tube mill machine

Material

carbon steel

Mechanical properties

σb≤520Mpa,σs≤365MPa

Strip Width

600-1200mm

Strip Thickness:

3-8mm

Inner Diameter of Coils

Φ508mm

Outer Diameter of Coils

Φ1300～φ2000mm

Coil Weight

≤12T

(2)Pipe Specification

Pipe Diameter

Round pipe:φ180-350mm
Thickness:3-8mm

Length

6-12m

Pipe-cutting Precision

0-6mm

Forming Speed

max 80m/min for 8 mm thickness

(3)The buyer should self-supply

Work shop

95x12m, H＞5m(crane to ground)

Power

Approx.850KW 380V/60Hz/3phases

Circulation Cooling Water(whole system)

Flow:30+30 CBM
Pool Volume:40m3

Compressed Air
(whole system)

Flow:5m3/min
Pressure: 5-7kg/ cm2

Cable

All cable outside of my machine, you buy after machine fix location.

Working Process for tube mill machine

strip steel to coil→uncoiler →end straightener→flattener→shear welder→storage material unit →formed,welding,cooling,accurate pipe Dia. size →accurate pipe length size,cutting→inspection →package

Quality and After-sale Service Warranty for tube mill machine installation and commissioning


Equipment arriving at the buyer, the technical services personnel at the scene debugging, maintenance, equipment commissioning, commissioning, operation and maintenance instruction, responsible for technical training for equipment operation and maintenance personnel of the buyer. Used in users abide by the rules, under normal operating equipment, since 12 months from the date of the arrival of the equipment, such as positively impact on the quality to use, parts damage lead to equipment can't normal work, factory will give the repair or replacement free of charge.

350mm Api High Frequency Welding Tube Mill Machine

Our Factory
350mm Api High Frequency Welding Tube Mill Machine
Our Office
350mm Api High Frequency Welding Tube Mill Machine
Our Team
350mm Api High Frequency Welding Tube Mill Machine
Past Project
350mm Api High Frequency Welding Tube Mill Machine
Machine and Management Certificate
350mm Api High Frequency Welding Tube Mill Machine
