12.8V 72Ah Solar Battery Storage System LFP Home Solar Battery
12.8V 72Ah Solar Battery Storage System LFP Home Solar Battery
12.8V 72Ah Solar Battery Storage System LFP Home Solar Battery
12.8V 72Ah Solar Battery Storage System LFP Home Solar Battery
Specifications
Brand Name :
CTS
Model Number :
CTS-LFP12.8V 72AH
Certification :
CE
Place of Origin :
Hunan,China
MOQ :
10 unit
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5000 untis per month
Delivery Time :
7-15 working days
Packaging Details :
Wooden case and Carton case
Nominal Voltage :
12.8V
Nominal :
72Ah
Energy :
921.6Wh
Charge Voltage :
14.6±0.2V
Plastic Case :
ABS
Dimension(L*W*H*TH) :
260*169*213*218mm
Weight :
9.4kg
Terminal :
M6
Description

Custom 12v 12.8v 72ah Lifepo4 Battery For Inverter Solar System

Custom 12v 12.8v 72ah Lifepo4 Battery For Inverter Solar System

Features:

1.Built-in automatic protection for over-charge,over-discharge and over-temperature conditions.
2.Maintenance free.
3.Internal cell balancing.
4.Communication of monitored data via Battery Management System (BMS).
5.Thousands of cycles,100% DOD,under normal conditions.
6.Can be charged using most standard lead-acid chargers (set for AGM/GEL cells).
7.Flame retardant plastics.

Specifications:

Nominal Voltage

12.8V

Nominal Capacity

72Ah

Energy

921.6Wh

Internal Resistance

50≤mΩ

Cycle Life

>2000 Cycles @ 0.2C Charge/Discharge at 100%DOD,End of Life 70% Capacity

Months Self Discharge

≤3.5% per month at 25℃

Charge Voltage

14.6±0.2V

Charge Mode(CC/CV)

At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C5A, and

then,changed continuously with constant voltage of 14.6V until the current was not

more than 0.02C5A.

Charger Current

14.4A

Max.Charge Current

36A

Discharge Current

14.4A

Max. Continuous Current

72A

Max.Pulse Current

80A(<3S)

Disxcharge Cut-off Voltage

10.0V

Charge Temperature

0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity

Disxcharge Temperature

-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity

Storage Temperature

0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity

Water Dust Resistance

IP55

Cell & Method

IFR32700 N60,4S9P

Plastic Case

ABS

Dimension(L*W*H*TH)

260*169*213*218mm

Weight

9.4kg

Terminal

M6

Applications:

1. Large-scale electric vehicles: electric bus, electric car, E-Tour Car.
2. Light electric car: e-bike, e-scooter,e-motorcycle, electric golf cart, e-wheelchair.
3. E-tool: electric drill, electric saw, lawn mower and so on.
4. Remote control cars, boat, aircraft, toys.
5. Solar and wind power generation energy storage devices, Telecom base Station.
6. Small medical equipment and portable equipment.

12.8V 72Ah Solar Battery Storage System LFP Home Solar Battery

FAQ:

1): Are you manufacturer or simply trading company?

Re: We are manufacturer, and we sincerely welcome you to visit our factory!

2): Can I get a lower price if I order large quantities?

Re: Yes, cheaper prices with more bigger size orders.

3): Do you offer charger for battery?

Re: Yes, we do. If you also need charger, please mention it when sending inquiry, kindly note that our charger cost is not included in the battery cost.

4): How about your company intelligence?

Re: ISO9001 certification, China Hi-tech company, 10 million battery assurance, 8 patents, Almost all products are MSDS, UN38.3, IEC62133, CB,etc certificated.

5): When you ship my order?

Re: Normally 5-10days after receiving your payment, but it can be negotiated based on order qty and production schedule.

6): How about the quality guarantee period?

Re: Two year!
