Specifications
Brand Name :
KHJ
Model Number :
E1-IH807J
Certification :
RoHS
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10000 square meters/day
Delivery Time :
3~5days after payment done
Packaging Details :
Plastic bag + carton
Product name :
E1-IH807J
Backing Thickness :
0.025mm
Total Tape Thickness :
0.045±0.005mm
Static Discharge (Removal from roll) :
<100V
Elongation at Break :
≥45%
Upmost Temperature :
270℃
Description

Polyimide Film Backed Heat Resistant Adhesive Tape ils Silicone Tensile Elongation

Polyimide film-backed silicone adhesive polyimide tape E1-IH807J with excellent tensile strength and elongation

E1-IH807J is a polyimide film-backed silicone adhesive polyimide tape which has ils thickness with good adhesion ,also low electrostatic discharge properties.

Features And Benefits:

1. Low electrostatic discharge at unwind and removal.

2. Resistant high temperature up to 270℃.

3. Excellent tensile strength & Elongation.

Die-cutting and formed any shape for general masking.

4. RoHS Compliant.

Application:

Masking for golden finger of Print circuit boards when wave soldering or reflow soldering process, surface protection under the high temperature without any residue.

Properties:

Product high temperature resistant tape Units Test values
Backing Thickness: mm 0.075
Total Tape Thickness: mm 0.09±0.005
Adhesion to Steel: N/25mm 3~4N
Tensile Strength at Break: KN/M ≥8
Elongation at Break: % ≥50%
Upmost Temperature ° C 270
Surface Resistance ohms 105~9ohms
Static Discharge(Removal from roll) Voltage <100V

Construction:

Polyimide Film Backed Heat Resistant Adhesive Tape il Silicone Tensile Elongation

Storage:

1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of direct sunlight.

2. Shelf life: 12 months from the date of manufacture when stored in initial packing.

Precaution Reminder:

1. Surface should be clean, dry, free of dust, oil or other contaminants.

2. Proper pressure required by roller, hand or press when applying.

3. Avoid repeat sticking to prevent adhesion decrease.

Why choose us?

1. Professional tape manufacturer for nearly 20 years.

2. Gold supplier.

3. Provide samples and best service.

Why buy from us instead of buying from other suppliers?

1. Good reputation and after-sales service team.

2. Good location and convenient transportation.

Notes:

Please be advised that this technical data sheet is written based on our lab tests and experience only. Customer is responsible to determine the suitability of the product meets intended application requirements before approved for use.
