4 Ports ODF FTTH Distribution Terminal Box 19 Inch Standard Rack Mount
4 Ports ODF FTTH Distribution Terminal Box 19 Inch Standard Rack Mount
4 Ports ODF FTTH Distribution Terminal Box 19 Inch Standard Rack Mount
4 Ports ODF FTTH Distribution Terminal Box 19 Inch Standard Rack Mount
4 Ports ODF FTTH Distribution Terminal Box 19 Inch Standard Rack Mount
4 Ports ODF FTTH Distribution Terminal Box 19 Inch Standard Rack Mount
Specifications
Brand Name :
BLG /OEM
Model Number :
4 port ODF
Certification :
CE/ROHS/ISO
Place of Origin :
China
MOQ :
10 pieces
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
1000pcs/week
Delivery Time :
4~10days
Packaging Details :
One piece in one paper box, Several boxes /carton.
External size :
1U
Material :
Cold-rolling steel/SPCC/AL
Type :
19 inch standard Rack mount
Key Word :
FTTH terminal box
SIZE(cm) :
20*11*3.4
Description

4 Ports ODF Fiber Optic Cable Assemniles FTTH Fiber

Optical Distribution Terminal Box

1. Description:

The 4/8/12/24ports Fiber Terminal Box is used to connect the fiber in the house and

it can be hanged on the wall or fixed on the floor. The body is made of steel plate with

rot-resistant coating. For meeting the new development of communication network, the

products considered to be new small distribution cabinets, it is applied for remote

module offices, BTS, etc. DDF, ODF modules are integrated in the same equipment,

so the original functions are realized and do save space and be easy to manage.

2. Technical Data:

Item

fiber optic terminal box

size

200*110*34

Material

Cold rolled steel

Max capacity

8 port

inlet/outlet ports

4 ports

Installation type

wall-mounted

Pigtail type

SC/FC.LC.ST

Operating Temperature

-25~+40 ℃.

Relative Humidity

≤85%(+30 ℃)

Insulation Resistance

>2*10^4MΩ

Anti-dielectric

<15KV

3. Features:

1). Design for MPO/MTP SYSTEM, for quickly network deploy and quick-fix solution

2). High-density and small design;

3). 12 and 24 fiber versions – 12 LC (Duplex) / SC (Simplex) optical parts

4). Available Multimode (62.5/125, Standard 50/125 and OM3,OM4) and Single

mode(OS1/2) fiber.

5). Factory-terminated and -tested cable and apparatus for instant field connections

with guaranteed quality and performance

6). Metallic shell with high strength protect the inner fibers effectively

7). Supports easy reconfiguration for moves, adds, and changes

8). Available for the installation of LC/SC adapter.

4. Application:

1). Cross connection cabinet widely used in FTTH (Fiber To the Home) access

network.


2). Telecommunication Networks

3). CATV Networks

4). Data communications Networks

5). Local Area Networks


6). Suitable for Telecom UniFi.
