ABS Box Type DWDM Mux Demux 4 Channel Low Insertion Loss With 900um Fiber
ABS Box Type DWDM Mux Demux 4 Channel Low Insertion Loss With 900um Fiber
ABS Box Type DWDM Mux Demux 4 Channel Low Insertion Loss With 900um Fiber
ABS Box Type DWDM Mux Demux 4 Channel Low Insertion Loss With 900um Fiber
Specifications
Brand Name :
Linkopto , or OEM
Model Number :
HTU-4CH-DWDM-Mux ( Demux )
Certification :
CE, FCC, ROHS, TUV, ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Get latest price
Payment Terms :
T/T, WU, PayPal, Moneygram, L/C
Supply Ability :
80,000 Channels per month
Delivery Time :
2~7 working days
Packaging Details :
1-2pcs per carton case for DWDM
Product Name :
DWDM Mux Demux
Model Name :
ETU-4CH-DWDM-Mux ( Demux )
Channel Number :
4CH
Fiber Length :
1.5M or Customized
Wavelength :
ITU Grid C-Band
Express Port :
Customized
Monitor Port :
Customized
Connector Type :
LC, SC, FC, ST (UPC or APC)
Fiber Type :
900um, 2mm or 3mm fiber
Package type :
ABS Plastic box, LGX box, 1RU Rackmount or Customized
Channel Space :
100GHZ or 200GHZ
Description

PN: ETU-8CH-DWDM-Mux ( Demux )

4CH 100GHZ DWDM Mux Demux Module ABS box type with LC/UPC Connectors 900um Fiber

Description

Linkopto 4CH DWDM MUX DEMUX Modules with 50GHz/100GHz/200GHz channel spacing can be used to combine or separate wavelength channels at standard ITU grid. The DWDM modules passively multiplex the optical signal outputs from 4 or more electronic devices, and send them over a single optical fiber and then de-multiplex the signals into separate, distinct signals for input into electronic devices at the other end of the fiber optic link. Our standard package types of DWDM MUX DEMUX are Field Module ABS Plastic Box, 19" Rack Mount Chassis and LGX Metal Cassette Box.

Features

Ø Low Insertion Loss

Ø High Isolation

Ø Low PDL

Ø Compact Design

Ø Good channel-to-channel uniformity

Ø Wide Operating Temperature: From -40℃ to 85℃

Ø Wide Operating Wavelength: From 1260nm to 1620nm

Ø High Reliability and Stability

Applications

Ø PON Networks

Ø DWDM System

Ø CATV Links

Compliance

Ø ITU-T G.694.1

Ø RoHS

Ø Telcordia GR-1209-CORE-2001

Ø Telcordia GR-1221-CORE-1999

Specifications (1×N DWDM Mux/Demux Module)

Parameters
Channel Space (GHz) 100 200
Channel Number 1*4 1*8 1*16 1*4 1*8 1*16
Center Wavelength (nm) ITU Grid
Center Wavelength Accuracy (nm) ± 0.05 ± 0.1
Channel Passband (@-0.5dB) (nm) 0.22 0.5
Fiber Type SMF-28e with 900um loose tube or customer specified
IL (dB) 1.8 3.0 4.0 1.7 2.9 3.8
Passband Ripple (dB) 0.35 0.4 0.5 0.35 0.4 0.5
Isolation (dB) Adjacent Channel 25 28
Non-Adjacent Channel 40
PDL (dB) 0.2
PMD (ps) 0.1
RL (dB) 45
Directivity (dB) 50
Maximum Optical Power (mw) 300
Operating Temperature (℃) -40~85
Storage Temperature (℃) -40~85
BOX Package (mm) 100*80*10 or 140*115*18
LGX Package 1U,2U
19’’ Rack mount Package 1U

Notes:
1) Specified without connectors.
2) Add an additional 0.2dB loss per connector.

DWDM Mux/Demux Module

ABS Box Type DWDM Mux Demux 4 Channel Low Insertion Loss With 900um FiberABS Box Type DWDM Mux Demux 4 Channel Low Insertion Loss With 900um Fiber

Products Overview:

ABS Box Type DWDM Mux Demux 4 Channel Low Insertion Loss With 900um FiberABS Box Type DWDM Mux Demux 4 Channel Low Insertion Loss With 900um Fiber

Ordering Information:

DWDM X X XX X XX X X XX
Link Channel Spacing Number of Channels Configuration 1st Channel Fiber Type Fiber Length In/Out Connector
DWDM E 1=100GHz 04=4 Channel M=Mux 21=Ch21 1=Bare fiber 1=1m 0=None
2=200GHz 08=8 Channel D=Demux …… 2=900um loose tube 2=2m 1=FC/APC
5=50Ghz 16=16 Channel 34=Ch34 3=2mm Cable S=Specify 2=FC/PC
…… 4=3mm Cable 3=SC/APC
50=Ch50 4=SC/PC
…… 5=ST
6=LC
S=Specify
