Pluggable Cisco Fiber Module 300m Transmission Low Power Consumption
Pluggable Cisco Fiber Module 300m Transmission Low Power Consumption
Pluggable Cisco Fiber Module 300m Transmission Low Power Consumption
Pluggable Cisco Fiber Module 300m Transmission Low Power Consumption
Pluggable Cisco Fiber Module 300m Transmission Low Power Consumption
Pluggable Cisco Fiber Module 300m Transmission Low Power Consumption
Specifications
Brand Name :
Linkopto , or OEM
Model Number :
LS85X-3LCD03
Certification :
CE, FCC, ROHS, TUV, ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Get latest price
Payment Terms :
T/T, WU, PayPal, Moneygram, L/C
Supply Ability :
20,000pcs per week
Delivery Time :
1~3 working days
Packaging Details :
10pcs/ plastic tray or individual
Product Name :
10G SFP+ Transceiver
Model Name :
LS85X-3LCD03
Wavelength :
850nm
Data Rate :
10G
Transmission Distance :
300m
Connector Type :
Duplex LC
DDM :
with
Working Environment :
Commercial 0~70℃
Compatibility :
Cisco, HP, H3C, Alcatel-Lucent, MikroTik, Juniper, Huawei, ZTE, Zyxel, etc
Description

PN: LS85X-3LCD03

10G-SFP-SRC 10G SFP+ SR 850nm 300m MM Duplex LC Compatible with Cisco

Description

LINKOPTO 850 nm VCSEL 10Gigabit SFP+ transceiver is designed to transmit and receive optical data over 50/125 μm or 62.5/125 μm multimode optical fiber.

LINKOPTO SFP+ SR module electrical interface is compliant to SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential. Data lines are internally AC coupled.

LINKOPTO module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI. SFI typically operates over 200 mm of improved FR4 material or up to about 150mmof standard FR4 with one connector.

Features

1. Hot Pluggable

2. Optical interface compliant to IEEE 802.3ae

3. Electrical interface compliant to SFF-8431

4. 850nm VCSEL transmitter, PIN photo-detector

5. Maximum link length of 300m on 2000MHz/km MMF

6. Operating case temperature: 0 to 70 °C

7. Low power consumption

8. Maximum link length of 300m on 2000MHz/km MMF

9. All-metal housing for superior EMI performance

10. Advanced firmware allow customer system encryption information to be stored in transceiver

11. Cost effective SFP+ solution, enables higher port densities and greater bandwidth

12. RoHS6 compliant (lead free)

Applications

Ø 10GBASE-SR at 10.3125Gbps

Ø 10GBASE-SW at 9.953Gbps

Ø Other optical links

Cisco Compatible List

LPT-XFP10G-BXD-40 10GBASE-BXD XFP BiDi, Tx1330/Rx1270nm 40km LC DDM
LPT-QSFP40G-SR4 40GBASE-SR4 QSFP+, 850nm 150m MMF MTP/MPO DDM
LPT-QSFP40G-CSR4 40GBASE-CSR4 QSFP+, 850nm 400m MMF MTP/MPO DDM
LPT-QSFP40G-LR4 40GBASE-LR4 QSFP+, 1310nm 10km SMF LC DDM Duplex
LPT-QSFP40G-LR42 40GBASE-LR4 QSFP+, 1310nm 20km SMF LC DDM Duplex
LPT-QSFP40G-ER43 40GBASE-ER4 QSFP+, 1310nm 30km SMF LC DDM Duplex
LPT-QSFP40G-ER4 40GBASE-ER4 QSFP+, 1310nm 40km SMF LC DDM Duplex
LPT-SFP25G-SR85 25GBASE-SR SFP28, 850nm 100m MMF LC DDM Duplex
LPT-QSFP100G-SR4 100GBASE-SR4 QSFP28, 850nm 100m MMF MTP/MPO DDM
LPT-QSFP28-CWDM4 100GBASE-CWDM4 QSFP28, 1310nm 2km SMF LC DDM Duplex
LPT-QSFP100G-LR4 100GBASE-LR4 QSFP28, 1310nm 10KM SMF LC DDM Duplex
LPT-QSFP100G-ER4 100GBASE-LR4 QSFP28, 1310nm LWDM 25KM SMF LC DDM Duplex
LPT-QSFP100G-ER4L 100GBASE-ER4L-S QSFP28, 1310nm 40km SMF LC DDM Duplex

Quality Control

Pluggable Cisco Fiber Module 300m Transmission Low Power Consumption

OEM and ODM

OEM/ODM order is available

Shipment

International Express: DHL, FedEx,EMS,TNT, UPS and so on. It takes 3-7 days.

Guarantee
We promise all the advertised optical modules are brand new and absolutely never use old and refurbished materials. All the optical modules have been through functional test and aging test. We provide 3 years warranty for all the optical transceivers from the date of shipment.

LINKOPTO Package

Pluggable Cisco Fiber Module 300m Transmission Low Power Consumption
