Specifications
Brand Name :
Linkopto , or OEM
Model Number :
ES-T1-R
Certification :
CE, FCC, ROHS, TUV, ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Get latest price
Payment Terms :
T/T, WU, PayPal, Moneygram, L/C
Supply Ability :
20,000pcs per week
Delivery Time :
1~3 working days
Packaging Details :
10pcs/ plastic tray or individual
Product Name :
Copper-T SFP Transceiver
Model Name :
LI-T1-R
Data Rate :
1000Base-T
Transmission Distance :
100M
Connector Type :
RJ45 connectors
Working Environment :
Commercial 0~70℃
Compatibility :
Cisco equipment
DDM :
No
Description

Copper SFP 1000M Copper-T SFP GLC-TE 100M Compatible with Cisco

Features

Ø Up to 1.25Gb/s bi-directional data links

Ø Hot-pluggable SFP footprint

Ø Fully metallic enclosure for low EMI

Ø Access to physical layer IC via 2-wire serial bus

Ø TX Disable and RX Los/without Los function

Ø Compact RJ-45 connector assembly

Ø Low power dissipation (1.05 W typical)

Ø 1000 BASE-T operation in host systems with SERDES interface

Ø Operating case temperature range of

0°C to +70°C (Commercial)

-20°C to +85°C (Extend)

Applications

Ø Fiber Channel

Ø Gigabit Ethernet

Ø Router/Server interface

Ø Switch to Switch interface

Ø Switched backplane applications

Ø Other optical transmission systems

Description

linkopto`s RJ45 Copper Small Form Pluggable (SFP)transceivers is high performance, cost effective module compliant with the Gigabit Ethernet and 1000BASE-T standards as specified in IEEE 802. 3-2002 and IEEE 802.3ab, which supp- orting 1000Mbps data- rate up to 100 meters reach over unshielded twisted-pair category 5 cable. The module supports1000 Mbps full duplex data-links with 5-level Pulse Amplitude Modulation (PAM) signals. All four pairs in the cable are used with symbol rate at 250Mbps on each pair. The module provides standard serial ID information compliant with SFP MSA, which can be accessed with address of A0h via the 2wire serial CMOS EEPROM protocol. The physical IC can also be accessed via 2wire serial bus at address ACh.

By RJ45 SFP 1.25G Copper Ethernet Transceiver  , Pluggable Cisco Copper Gbic Module

Quality Control

By RJ45 SFP 1.25G Copper Ethernet Transceiver  , Pluggable Cisco Copper Gbic ModuleBy RJ45 SFP 1.25G Copper Ethernet Transceiver  , Pluggable Cisco Copper Gbic Module

By RJ45 SFP 1.25G Copper Ethernet Transceiver  , Pluggable Cisco Copper Gbic ModuleBy RJ45 SFP 1.25G Copper Ethernet Transceiver  , Pluggable Cisco Copper Gbic Module

Package

By RJ45 SFP 1.25G Copper Ethernet Transceiver  , Pluggable Cisco Copper Gbic Module

Related Product List

Item No. Description
SFP-BX-U-10 1.25G Tx1310nm/Rx1550nm 10km DOM BiDi SFP LC
SFP-BX-D-10 1.25G Tx1550nm/Rx1310nm 10km DOM BiDi SFP LC
SFP-2GBX-U-S20 2.5G Tx1310nm/Rx1550nm 20km DOM BiDi SFP SC
SFP-2GBX-D-S20 2.5G Tx1550nm/Rx1310nm 20km DOM BiDi SFP SC
SFP-BX-U-S40 1.25G Tx1310nm/Rx1550nm 40km DOM BiDi SFP SC
SFP-BX-D-S40 1.25G Tx1550nm/Rx1310nm 40km DOM BiDi SFP SC
SFP-BX-U-S80 1.25G Tx1490nm/Rx1550nm 80km DOM BiDi SFP SC
SFP-BX-D-S80 1.25G Tx1550nm/Rx1490nm 80km DOM BiDi SFP SC
SFP-BX-U-L120 1.25G Tx1490nm/Rx1550nm 120km DOM BiDi SFP LC
SFP-BX-D-L120 1.25G Tx1550nm/Rx1490nm 120km DOM BiDi SFP LC
SFP-10G-T 10G Copper RJ45 SFP Module 30M
XFP-10G-LR Dual LC 10G 1310nm 20km LR XFP+
SFP-10G-ER Dual LC 10G 1550nm 40km ER SFP+
SFP-10G-ZR Dual LC 10G 1550nm 80km ZR SFP+
SFP-10G-ZR100 Dual LC 10G 1550nm 100km ZR SFP+
SFP/SFP+ Compatible Cisco ASR 1001-X 1002-X
Zyxel XGS-2210-28 and zyxel XGS-4600-32
EPON OLT PX20+ 1.25G/1.25G Tx1490nm/Rx1310nm EPON OLT SFP PX20+
Compatible Chinese OLT
