LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM
LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM
LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM
LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM
Specifications
Brand Name :
Linkopto , or OEM
Model Number :
EXB23X-3LCD20
Certification :
CE, FCC, ROHS, TUV, ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
Get latest price
Payment Terms :
T/T, WU, PayPal, Moneygram, L/C
Supply Ability :
20,000pcs per week
Delivery Time :
1~3 working days
Packaging Details :
10pcs/ plastic tray or individual package
Product Name :
10G XFP BIDI TRANSCEIVER
Model Name :
EXB23X-3LCD20
Wavelength :
Tx1270/1Rx1330NM
Data Rate :
10G
Transmission Distance :
20KM
Connector Type :
Simplex LC
DDM :
with
Working Environment :
Commercial 0~70℃
Compatibility :
Cisco
Description

10Gbps XFP Bi-Directional Transceiver 20KM Reach

Rx1270/Rx1330 nm

Features

Ø Supports 9.95Gb/s to 10.5Gb/s bit rates

Ø Hot-pluggable XFP footprint

Ø Maximum link length of 20KM with SMF

Ø 1270nm DFB laser Transmitter ,and 1330nm Receiver

Ø XFP MSA package with LC connector

Ø No reference clock required

Ø Loop Back Support.

Ø +3.3V,+1.8V power supply

Ø Power dissipation <2W

Ø Compatible with RoHS

Ø Built-in digital diagnostic functions

Ø Temperature range 0°C to 70°C

Applications

Ø 10GBASE-LR at 10.3125Gbps

Ø 10GBASE-LW at 9.953Gbps

Ø 10GBASE-BX 10G Ethernet

Product Description

compliant with the IEEE803.3ae 10Gbase-Bx. and transmission distance up to 20KM on SMF.

The transceiver module comprises a transmitter with a 1270nm DFB laser transmitter, an integrated 1330nm detector preamplifier(IDP) mounted in an optical header and a limiting post-amplifier IC. Transmitter and receiver are separate within a wide temperature range of 0℃ to +70℃ and offers optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10GbE systems.

​Quality Control

LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NMLC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM

LC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NMLC Connector 10G BIDI Sfp Transceiver Module Tx1270 1Rx1330NM

Linkopto NO
Date Rate
Wavelength(nm)
Source
Connector
Reach
BIDI-XFP-LR-27
10G
Tx1270/Rx1330
DFB+PIN
LC
20km
BIDI-XFP-LR-33
10G
Tx1330/Rx1270
DFB+PIN
LC
20km
BIDI-XFP-ER-27
10G
Tx1270/Rx1330
DFB+PIN
LC
40km
BIDI-XFP-ER-33
10G
Tx1330/Rx1270
DFB+PIN
LC
40km
BIDI-XFP-ER+-27
10G
Tx1270/Rx1330
DFB+APD
LC
60km
BIDI-XFP-ER+-33
10G
Tx1330/Rx1270
DFB+APD
LC
60km
BIDI-XFP-ZR-49
10G
Tx1490/Rx1550
EML+APD
LC
80km
BIDI-XFP-ZR-55
10G
Tx1550/Rx1490
EML+APD
LC
80km
