Single Phase Motor Run Capacitor CBB65 50+5uF 370VAC For Compressor
Single Phase Motor Run Capacitor CBB65 50+5uF 370VAC For Compressor
Single Phase Motor Run Capacitor CBB65 50+5uF 370VAC For Compressor
Single Phase Motor Run Capacitor CBB65 50+5uF 370VAC For Compressor
Single Phase Motor Run Capacitor CBB65 50+5uF 370VAC For Compressor
Single Phase Motor Run Capacitor CBB65 50+5uF 370VAC For Compressor
Specifications
Brand Name :
ETOPMAY
Model Number :
TMCF23
Certification :
SGS( RoHS)
Place of Origin :
China
MOQ :
500
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
1000000pcs per month
Delivery Time :
15~20 working days
Packaging Details :
Bulk
Capacitance :
50+5uF
Voltage :
450VAC
Tolerance :
± 5%
Operating Temperature :
-25 ~ +70 °C
Dielectric :
Metalized Polypropylene
Case Material :
Aluminum
Frequency :
50/60 Hz.
Dissipation Factor :
0.0015 (100 Hz)
Description

Single-Phase Motor Run Capacitor For Compressor CBB65 50+5uF 370VAC

Brief Introduction

CBB65 motor run capacitors offer outstanding electrical characteristics, high capacitance stability over time and temperature, and very low internal power losses (Dissipation Factor). Case is aluminum round-shaped cans and standard terminations are 2- or 4-spade quick-disconnect terminals. Options available at an added cost include bleeder resistors and mounting brackets.

Features

  • Cylindrical aluminum shell, small volume, light weight.
  • Low dissipation, high insulation resistance
  • Good self-healing character, anti-striking current
  • Strong over-carrier capacity and steady electric performance
  • Reliable safety with inner anti-explosion device

Applications

CBB65 starting capacitors are widely used in the start-up and operation of single-phase motors powered by 50Hz/60Hz AC power supply, such as household air conditioners, and power factor compensation of high-power lighting fixtures.

Specifications

No. Items Specifications
01 Capacitance 50+5μF ±5%
02 Rated Voltage 450VAC
03 Life Class C
04 Dielectric Material Metallized Polypropylene Film
05 Rated Frequency 50/60Hz
06 Between Terminals Withstand voltage Applied voltage of 740VAC between two terminals for 60s, no phenomenon of breakdown and spark over.
07 Terminals to case Withstand voltage Applied voltage of 2500VAC to terminals to case for 60s, no phenomenon of breakdown and spark over.
08 Loss Tangent Less than 0.002(100Hz)
09 Size(mm) 50*125
10 Terminals 0.5 square RV wire, crimping ends, stripped wire length=6mm, cooper shell: 4mm
11 Climatic Category 40/85/21
12 Explosion-proof S2
13 Case material Aluminum
14 Terminal

250＃

Dimensions

Rated cap 250/300VAC 400/450VAC
Cylindrial Oval Cylindrial Oval
D
(mm)		 H
(mm)		 L*W*H
(mm)		 D
(mm)		 H
(mm)		 L*W*H
(mm)
10μF 40 55 51.5*31.5*65 40 65 51.5*31.5*65
15μF 40 55 51.5*31.5*65
20μF 40 65 51.5*31.5*75 40 75 51.5*31.5*75
25μF 40 65 51.5*31.5*75 45 85 51.5*31.5*85
30μF 45 95 71.5*45*75
32μF 40 75 71.5*45*65
35μF 50 95 71.5*45*85
40μF 45 75 71.5*45*75
50μF 45 85 71.5*45*85 50 125 71.5*45*100
60μF 45 95 71.5*45*100

Single Phase Motor Run Capacitor CBB65 50+5uF 370VAC For Compressor

Single Phase Motor Run Capacitor CBB65 50+5uF 370VAC For Compressor

FAQ Of Topmay Capacitor

1) Can I have a free sample to test ?
Yes, we could provide free samples to test and check quality. Freight cost is collected.

2) What is the lead time?
Sample needs about 7~10 working days prepared; mass production average time takes 15-20 working days

3) Do you have any MOQ limit?
Yes. But it depends on product. Normally MOQ is 2K~10Kpcs

4) How about price terms?

We do FOBSHENZHEN if order amount is more than 5000USD. Less than that, it is EXWSHENZHEN and we do not undertake local charge.

5) What information should I let you know if I want to get a quotation?

Basically for capacitor, it requires to know detailed capacitance and voltage. If you have more information, such as type, product photo for reference, you could kindly provide too.

Single Phase Motor Run Capacitor CBB65 50+5uF 370VAC For Compressor

Our series of strong products of capacitors can be divided into below types:
★ Ceramic Disc Capacitor( low and high voltage, Y1/Y2 safety )
★ Multilayer Ceramic Capacitor( radial, axial and SMD )
★ Film Capacitor( Mylar, MKT, MKP, X2, CBB60, CBB61, CBB65, CL21-Box, CBB-BOX, CL20, CBB20, CBB81, etc. )
★ Aluminum Electrolytic Capacitor(SMD, Radial , Axial, Snap-in , Screw Terminal, etc. )
★ Tantalum Capacitor(SMD, Radial , Axial )
★ Super Capacitor( Coin Type, Cylindrical Type, Module Type)
★ Mica Capacitor
★ Trimmer Capacitor

And series of resistors which we develop new production lines are as below:
★ SMD Resistors
★DIP TYPE Resistors( KNP, CF, MF, MOF, ect,)
★ Cement Resistors
★ Leadless Resistors( MLEF)
★Power Resistor

More details, kindly contact us freely!
