Telescopic Boom Vessel Earnest Provision Crane on Ship Design Marine Ship Deck Crane
Telescopic Boom Vessel Earnest Provision Crane on Ship Design Marine Ship Deck Crane
Specifications
Brand Name :
HAOYO
Model Number :
HAOYO
Certification :
ABS,BV,CCS,DNV,LR,NK
Place of Origin :
China
MOQ :
1 unit
Price :
20000-30000USD/Set
Payment Terms :
T/T,L/C
Supply Ability :
300 UNITS
Delivery Time :
90days
Packaging Details :
NUDE
Use Situation :
New
Operstion formal :
Ground operation
Shipment Parameters :
According to The Export Standards
Specification :
According to The Export Standards
Trademark :
HAOYO
Origin :
Shanghai
Sling Type :
Wire Rope
Description


Telescopic Boom Vessel Earnest Provision Crane on Ship Design

Telescopic Boom cranes offer the power, reach, and dexterity for the most demanding
marine applications. The telescopic series of cranes offer a diverse product line for
application in Provision cranes, Service cranes, Workboat, Container and cargo
handling cranes Luxury Yacht, Oilfield, or Military industries.
Telescopic Boom Vessel Earnest Provision Crane on Ship Design Marine Ship Deck Crane

Drawing(Telescopic Boom Vessel Earnest Provision Crane on Ship Design)
Telescopic Boom Vessel Earnest Provision Crane on Ship Design Marine Ship Deck Crane
Technical Parameters

MODELSafety Load
(KN)		Max Outreach
(m)

Lifting Speed
(m/min)

Slewing Speed
(r/min)		Luffing Time
(s)		Hoisting Height
(m)		Slewing Angle(°)Permissible Heeling(transverse/
longitudinal)(°)

Power
(kW)

10106~201516030360°2° /5°7.5
15158~221516030360°2° /5°11
20205~241516030360°2° /5°15
30308~25150.97030360°2° /5°22
505012~25150.758030360°2° /5°37
808012~25150.7510040360°2° /5°55
10010012~25150.7511040360°2° /5°75
15015012~28150.611030360°2° /5°90
20020016~30150.612035270°2° /5°75*2
25025020~35150.513040270°2° /5°90*2
30030035150.414040270°2° /5°90*2
35035020~40150.515045360°2° /5°110*2
40040020~40150.515045360°2° /5°140*2
45045025~40150.4516050360°2° /5°140*2
50050020~40150.4517050360°2° /5°165*2


Production Flow
Telescopic Boom Vessel Earnest Provision Crane on Ship Design Marine Ship Deck Crane
Certifications(Telescopic Boom Vessel Earnest Provision Crane on Ship Design)
Telescopic Boom Vessel Earnest Provision Crane on Ship Design Marine Ship Deck Crane

Packaging & Delivery
Telescopic Boom Vessel Earnest Provision Crane on Ship Design Marine Ship Deck Crane
Shipping details
♦ check all the items and packaged well before loading.
♦ You can check loading or send picture to you.
♦ After shipping make documents for you,like B/L,packing list,voice according
to your requirements.


About us

Telescopic Boom Vessel Earnest Provision Crane on Ship Design Marine Ship Deck Crane
Contact us

Miss Wang ---Foregin trademan
Hp: 0086-17521634863
Email: cindy@haoyogroup.com


OFFICE ADD: NO. 500, JIANYUNRD,PUDONG,SHANGHAI
FACTORY ADD: INDUSTRIAL PARK, CHANGSHU, JIANGSU
Web: www.haoyogroup.com
