BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
Specifications
Brand Name :
HAOYO
Model Number :
HAOYO-HC
Certification :
BV,CCS,NK,ABS,DNV,LR
Place of Origin :
China
MOQ :
1 unit
Price :
USD 20000-50000
Payment Terms :
T/T,L/C
Supply Ability :
30 pieces per year
Delivery Time :
90days
Packaging Details :
NUDE
Use Situation :
New
Color :
as required
Operation formal :
Ground operation
Shipment Packaging :
According to The Export Standards
Trademark :
HAOYO
Origin :
Shanghai
Sling Type :
Wire Rope
Type of crane :
Foldable boom marine crane
Application :
Service Crane, Provision and Cargo Lifting Crane, Service Crane, Fishing Crane
Features :
Flexible and Strong, Saving Space,Multi-function
Description
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
This Offshore Marine Ship hydraulic Foldable Telescopic&Knuckle Boom crane
mostly used on oil tanker and port.the main parts use world famous brands promise
it has perfect performance.which has the function of easy convenient and reliable
to operation,flexible rotation,compact structure,and work very efficiency.
As a direct manufacturer ,we are specialize in different types crane such as fixed
boom crane telescopic boom crane, knuckle boom crane, folding arm crane, and
other marine and port machine. We can give you a low price and our experienced
engineers can meet customer different requirement and work condition.For after
sale service we will give you 18 months guarantee period with top technical support,
engineers can service overseas.
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
Drawing(BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale)
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
Certifications

BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale

MODEL Outreach
(m)		 Safety Load(kN) Lifting Moment(kNm) Total Moment (r/min) Pedestal Diameter (mm) Dead Weight (t)
ECK 150 8.0-12.0 2.1-1.1 132-168 241 885 2.8-3.2
ECK 250 10.0-14.0 2.9-1.8 242-290 381 885 3.7-4.3
ECK 350 12.0-16.0 3.6-2.3 370-430 603 1095 5.3-6.3
ECK 550 14.0-18.0 4.7-3.2 573-660 980 1325 7.8-9.2
ECK 750 14.0-18.0 6.1-4.2 749-855 1375 1490 11.5-12.8
ECK1150 16.0-20.0 7.3-5.2 1040-1160 1765 1490 12.7-14.0
ECK1450 16.0-20.0 9.0-6.4 1268-1440 2555 1770 19.2-23.0
ECK 220 27.5 30,0 2200 4000 1800 25.0
ECK 300 30.0 30.0 3000 5000 2065 27.5
ECK 400 32.0 30.0 4000 6300 2050 30.0
ECK 500 35.0 35.0 5000 8000 2240 35.0
ECK 800 37.0 50.0 8000 11500 2271 55.0
ECK1000 40.0 60.0 10000 14400 2536 70.0
ECK1200 43.0 80.0 12000 18000 2550 100.0
ECK1600 45.0 100.0 16000 34000 3166 150.0
ECK2000 50.0 125.0 20000 44000 3987 200.0
ECK2500 50.0 150.0 25000 50000 4000 220.0
ECK3000 50.0 200.0 30000 60000 4500 275.0

Other Products
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale

Company Information

BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale
BV, CCS, NK, LR, ABS Certified Hydraulic Marine Folding Crane For Sale

FAQ

Please provide following necessary information,so we can quote right Model crane.
1. What kind of marine crane do you need(stiff boom crane, telescopic boom crane

knuckle boom crane knuckle telescopic crane or folding boom crane )


2. Crane SWL requested(___ T/___M)
3. Max. working radius of the crane(___M)
4. The crane will be used on ship, offshore platform or fixed platform (motor 380V or 440V)
5. If you have any other special request for the crane, please advise us, we will design
the suitable model for you.
