22KW 7.2kWh Car EV Charger 32a Home Charging Unit IEC 61851 621961
22KW 7.2kWh Car EV Charger 32a Home Charging Unit IEC 61851 621961
Specifications
Product Name :
Home Car Charging Point
Charging Port :
3 ports, 2 ports, 1port, 4 ports, Type C
Output power :
11KW/22KW
Input Voltage :
230vac± 10% / 380vac ± 10%
Protocol :
OCPP-1.6 (JSON)
Standard :
IEC 61851-1, IEC 62196-1/2
Function :
Voltage Monitoring, temperature monitoring, LCD SCREEN, AUTOMATICAL REPAIR, leakage protection
Charging Standard :
level 1 level 2 level 3
Description

380V Electric Car Charging Piles EU Wall Mount EV Charging Station

EV Charging Power and Time
Charger AC/DC Rated Power 30kWh Battery 60kWh Battery 90kWh Battery
Schuko 16A AC 3.6kW 8hrs 16hrs 24hrs
Schuko 32A AC 7.2kWh 4hrs 8hrs 12hrs
1-phase 16A AC 3.6kW 8hrs 16hrs 24hrs
1-phase 32A AC 7.2kWh 4hrs 8hrs 12hrs
3-phase 16A AC 11kW 3hrs 6hrs 9hrs
3-phase 32A AC 22kW 1.5hrs 3hrs 4.5hrs
DC Fast charge DC 50kWh 40mins 80mins 120mins
Tesla Supercharger DC 120kW 15mins 30mins 45mins

Basic Data
Output current
16A
Output power
11KW @ AC 400V
Charging Plug
Type 2
Cable
5m / customizable
Function and Accessory
WIFI/4G
No
Screen
OLED Display
LED Indicator light
Flash
RFID
YES
Protection
Leakage detection and protection
YES
Double Lightning Protection
YES
Emergency stop button
YES
Over-voltage Protection
YES
Under-voltage
YES
Over-temp Protection
YES
Water-proof Protection
IP 65
Over current Protection
YES
Operating Temperature
-30℃~50℃
Leakage protection
AC 30mA DC 6mA
Package
Dimension (W/H/D)
54*44*17cm
Weight
7.5KG
Packing Methord
Netruel box
Guarantee
Warranty
12 months
Certificate
TUV CE

Each charger will be fully inspection to ensure product performance in good condition:

Withstand voltage insulation test - start high voltage machine test
Charging preparation -- measuring input voltage
Charging connection confirmation - measuring resistance
Ready to charge - measure current
Ready to charge - measuring frequency
Start up and charging stage - measure the output voltage
Start up and charging phase - measuring output current
Normal charge end test - measure output voltage


CP Disconnection Test: measure the output voltage after resuming charging
CP ground test - measure output voltage
Input overvoltage protection - measure output voltage
Input overvoltage protection - automatic recovery function, measuring output voltage
Input undervoltage protection - measure output voltage
Input undervoltage protection - automatic recovery function, measuring output voltage
Leakage protection - measuring output voltage
Overcurrent protection - measuring output current
Over current protection - automatic recovery function, measuring output current
