AC IP65 Electric Car Fast Wall Box EV Charger Home SAE J1772 Type 1 Type 2
AC IP65 Electric Car Fast Wall Box EV Charger Home SAE J1772 Type 1 Type 2
Specifications
Brand Name :
LINKIN
Type :
Wallbox Electric Vehicle Charger
Voltage :
380V/ 220V/240V
Charging Port :
Type 1, Type 2
Combination :
LED/LCD/ RFID/Emergency stop button, AC Charging Station
Cable length :
5 Meters/ Customized
Package :
Color Box
Output Current Range :
0~32A
IP Code :
IP 65
Description

OEM 7KW Electric Vehicle Wall Box EV Car Charger Station Type 1 Type 2 Charging Adapter

1. Load balance management:

* Restricting the total charging load protects the local grid
* Sharing the charging load cuts costs for the required electricity connection
* Choose an open type CT (current transformer) as the current sensor, It is no physical wiring between the devices, which has the advantage of open and close installation, convenient and fast wiring, no extra infrastructure or installation costs.

2. Protection:


* RCD Type B inside,it is more safe than Type A.
* High quality production and design standards for safe and reliable use with multiple fault protection: Overvoltage Protection,Undervoltage Protection, Overload Protection, Short Circuit Protection, Earth leakage Protection, Ground Protection, Over-temp Protection, Surge Protection and etc.

Specification

Power Specification
US Standard
EU Standard
Charging Connector Type
SAE J1772 (Type 1)
IEC 62196-2 (Type 2)
AC Power Input Rating
AC Level 2, 240V
230V±15%
Frequency Rating
50/60 Hz
AC Power Output Rating
3.5kw/16A
7kw/32A
10kw/40A (US Standard optional)
User Interface & Control
Emergency Stop Button
Yes
Plug-and-Charging
Yes
RFID Card Charging
Yes
App Charging
Yes
Ethernet Interface
Yes
Wifi Function
Yes
OCPP Protocol
OCPP 1.6
Protection
Over Voltage Protection
Yes
Under Voltage Protection
Yes
Over Load Protection
Yes
Short Circuit Protection
Yes
Earth Leakage Protection
Yes
Ground Protection
Yes
Over-temp Protection
Yes
Surge Protection
Yes
RCD
Type A
Environmental
Storage Temperature
-40 ~ 75℃
Operating Temperature
-30 ~ 55℃
Operating Humidity
Up tp 95%, non-condensing
Altitude
≤2000m
Cooling Method
Natural Cooling
M3P Wallbox Mechanical
IP Code
IP65
Dimension(H×W×D,mm)
310×220×95
Weight
7kg
Charging Cable Length
5m or Customize
Enclosure Material
PC
M3T Mounting Pole(Optional)
Dimension(H×W×D,mm)
1400×200×100
Weight
＜8kg
Enclosure Material
Metal

AC IP65 Electric Car Fast Wall Box EV Charger Home SAE J1772 Type 1 Type 2
