7kw 32a50HZ IP65 Electric Vehicle Home Charging Point Home Wallbox Charger
7kw 32a50HZ IP65 Electric Vehicle Home Charging Point Home Wallbox Charger
Specifications
Brand Name :
LINKIN
Type :
Wallbox EV Charger
Function :
screen display, Voltage Monitoring, colorful light
Charging Port :
Type 1, Type 2
Combination :
LED/LCD/ RFID/Emergency stop button, AC Charging Station
Cable length :
5 Meters/ Customized
Network Gateway :
Ethernet/Wifi/4G
Size :
398*324*120mm
IP Level :
IP65
Description

7kw 32a AC EV Wall Box Charger Type1 J1772 Plug Level 2 EVSE OCPP 1.6J EV Charging Station

Wallbox EV Charger Product Introduction

Emergency stop function, the charging process can be suspended immediately by emergency stop switch.

The AC commercial charging station integrates functions such as control, management, query and display, and has the advantages of reliability, flexibility, convenience,and speed, It is widely used in public parking lots, residential parking lots and other small and medium-sized electric vehicle charging places.

Function

• Smart: The mobile phone APP provides functions such as search, navigation, query, and appointment of charging.
• Seflient: Support services such as swiping cards and mobile apps
• System: Advanced cloud fast charging platform system, providing big data monitoring

Specification

AC Nominal Input
Phase
1phase+neutral+PE
Voltage
230V±10%
Frequency
50HZ
AC Nominal Output
Voltage
230v±10%
Current
32A
Power
7KW
Structure Design
Housing Material
PC+PBT
Front Panel
Temper glass
Installation Method
Wall-mount/Floor-stand
Charging Outlet
4M charging cable(Type1/Type2)
LED Indicator
Green /yellow/red/blue for different status
LCD Display
Display charging data
Emergency Stop Button
Yes
RFID Function
2pcs cards
Environmental Index
Protection Level
IP65 for Box
Temperature/Humidity
-30-50℃/5%-95% without condensation
Working altitude
＜2000M
Application Site
Indoor /Outdoor
Security Protection
Multiple Protection
Over current&Under voltage&over voltage&Residual current&Surge protection&short circuit&over temperature&ground fault&current leakage protection
Safety Standard
EN61851-1
MTBF
10000 Hours
Warranty
2 years
Package Information
Protection Dimension
398*324*120mm
Package size
490*385*275mm
Net Weight
8kg
Gross Weight
10.5kg
External Packing
carton
Optional Parts
Network Gateway
Ethernet/WIFI/4G communication
Communication Protocol
OCPP1.6(JSON)
RCD
TYPE B
Energy Meter
MID certified

FAQ

Q: How long is your delivery time?

For charging posts, it is usually 3-10 days. If there is no stock, the production lead time is determined according to the order quantity. High-power DC char- ging posts usually need to be customized according to the customer's technical parameters.

Q: How long does it take to customize the prototype?

For charging piles, the prototype time is usually 7 days.
For DC charging post, the prototype time is usually 15 days.
For high power fast charging station, the technical parameters need to be
determined before production, and the prototype time is usually 30 days.

Q: How to guarantee the service?

Our products are divided into two categories: household and commercial.
For home chargers, we provide standardized service: 1 year warranty + remote installation and usage guidance + video installation tutorial
For commercial chargers, we not only provide standardized services for charging piles, but also provide payment software docking services for opera
ting companies.

Q: How do you guarantee the quality of your products?

The charging post products we sell have passed GB certification in China and CE certification in EU. For some other countries, the relevant certifications are
in progress.

Q: How do you guarantee the quality of your products?

The charging post products we sell have passed GB certification in China and CE certification in EU. For some other countries, the relevant certifications are
in progress.
