OCPP 1.6 JSON Type 2 Socket 7KW Public Ev Charging Station
OCPP 1.6 JSON Type 2 Socket 7KW Public Ev Charging Station
Specifications
Brand Name :
Joint
Model Number :
EVC10-07C1S
Certification :
ETL, CE
Place of Origin :
China
MOQ :
1
Price :
USD 250-450/SET
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30000 pcs/Month
Delivery Time :
28 Days
Packaging Details :
Standard Package
Power Supply :
1Phase+N+PE or 3 Phase
Working Temperature :
-30C°~+50C°
Current :
32A
Frequency :
50/60Hz
Rated Power :
7KW
Charge Connector :
Type A+DC6mA (Type B)
LED Indicator :
Green/Blue/Red
Weight :
24.3lb-94.8lb
RFID Reader :
Optional
LCD Display :
4.3" LCD screen
Optional :
4G Module, WIFI, MID Certified Meter
Description

7KW OCPP 1.6 JSON Type 2 Socket 32Amp AC Commercial EV Charging Station

Features and advantages
1. Stylish durable design Up to 32A @ 240V Max. ouput power:7kw
2. Network connectivity OCPP 1.6J (2.0 compatible)
3. Type A+DC6mA
4. Waterproof LAN interface
5. IEC 62196-2 charging plug and 5m cable or socket
6. IK08, IP65 for indoor /outdoor
7. 4.3’’ LCD optional
8. 4G SIM card Emergency stop

Electric Vehicle Charging Station​ Specifications:

Model Name EVC10-07C1S EVC10-07C1C EVC10-22C1S EVC10-22C1C
Input Rating 230±10%Vac (One Phase) 400±10%Vac (Three Phase)
Frequency 50Hz
Input Current 32A
Output Current 32A
User Authentication RFID (ISO 14443)
External LAN (optional) + 4G (optional) or Wi-Fi (optional)
Internal OCPP 1.6 JSON (OCPP 2.0 compatible)
Operating Temperature -22˚F~122˚F(-30˚C~50˚C)
Humidity Max. 95% RH
Altitude ≦ 2000m
IP Level IP 54 IP65 for box IP 54 IP65 for box
Dimension(WxDxH) 350x250x175mm (13.8″x9.8″x6.9″) 350x250x130mm (13.8″x9.8″x5.1″) 350x250x175mm (13.8″x9.8″x6.9″) 350x250x130mm (13.8″x9.8″x5.1″)
Charging Outlet One Socket 5M Cable One Socket 5M Cable
RCD RCD TYPE B
Charging Interface Type 2 Plug
Multiple Protection

Over current, Under voltage, Over voltage, Residual current, Surge protection,

Short circuit, Over temperature, Ground fault, Current leakage protection

OCPP 1.6 JSON Type 2 Socket 7KW Public Ev Charging Station
