SAE J1772 240V 7.5KW 32Amp Level 2 Electric Vehicle Charger
SAE J1772 240V 7.5KW 32Amp Level 2 Electric Vehicle Charger
Specifications
Brand Name :
Joint
Model Number :
JNT-EVC10-07C1C-00
Certification :
ETL, CE
Place of Origin :
China
MOQ :
1
Price :
USD 250-450/SET
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
30000 pcs/Month
Delivery Time :
28 Days
Packaging Details :
Standard Package
Power Supply :
1Phase+N+PE
IP Rating :
IP65
Working Temperature :
-30C°~+50C°
Current :
32A
Frequency :
50/60Hz
Rated Power :
7.5KW
Charge Connector :
SAE J1772 Plug with 16ft Cable
LED Indicator :
Green/Blue/Red
Weight :
24.3lb-94.8lb
RFID Reader :
Optional
LCD Display :
4.3" RCD screen
Description

SAE J1772 Play and Plug 7.5 KW 32Amp 240V Level 2 AC EV Charger Station

Up to 6x faster charge: High-power, 32 amperes, 7.5 kW EV charging station. Indoor / outdoor installation. Built-in cable rack and security lock. UL listed certified. 3-year limited warranty for normal residential or commercial use.

Convenient WiFi connectivity: With the free app, control and monitor charging remotely, get notified when your car is fully charged, set reminders to charge, and more. Dynamic LED lights show charging status.

Smart grid savings: Schedule your charging times when rates are lower — making your electric vehicle even cheaper to drive.

Hardwire Installation: This unit is ready to be hardwired by a qualified electrician.

EV Charger Station Features:

Model Name
 EVC10-03C1C
EVC10-07C1C
EVC10-09C1C
EVC10-11C1C
Input Rating
200-240Vac
Frequency
60Hz
Input Current
16A
 32A 40A 48A
Output Current
16A
 32A 40A 48A
User Authentication
RFID (ISO 14443)
External
LAN (optional) + 4G (optional) or Wi-Fi (optional)
Internal
OCPP 1.6 JSON (OCPP 2.0 compatible)
Operating Temperature
-22˚F~122˚F(-30˚C~50˚C)
Humidity
Max. 95% RH
Altitude
≦ 2000m
IP Level
IP65 for box
Dimension(WxDxH)
350x250x130mm (13.8″x9.8″x5.1″)
Charging Outlet
18ft charging cable(25ft charging cable optional)
CCID
CCID20
Charging Interface
SAEJ1772
Multiple Protection
Over current, Under voltage, Over voltage, Residual current, Surge protection,
Short circuit, Over temperature, Ground fault, Current leakage protection
