JSON1.6 OCPP AC EV Charging Stations 7kW 22kw Home Charger
JSON1.6 OCPP AC EV Charging Stations 7kW 22kw Home Charger
JSON1.6 OCPP AC EV Charging Stations 7kW 22kw Home Charger
JSON1.6 OCPP AC EV Charging Stations 7kW 22kw Home Charger
Specifications
Brand Name :
ANS
Model Number :
ANS-T2AC22kW
Certification :
TUV/CE/UL/RoHS/REACH
Place of Origin :
China
MOQ :
1pcs
Price :
USD300-500
Payment Terms :
T/T, Western Union,Paypal, L/C
Supply Ability :
100pcs/day
Delivery Time :
10-30days
Packaging Details :
Carton box. Carton size: 43*43*21cm
Product Name :
22kW ev charging station
Cable Length :
5M or customized
Rated Current :
32A
Rated Power :
22kW
Rated Voltage :
480V
load manufacturer :
dynamic load manufacturer
Charging Control :
Plug and Play or RFID card
Connector Type :
IEC62196 Type 2
Description

7kW 22kW EV Charging Station with Dynamic Load Balance OCPP JSON1.6

Power Specification

Type B DC 6mA + 30mA AC leakage protector

Various startup modes,RFID card,APP,plug in and charge.

Load balancing management and solar matching function.

Saving on electricity bills by scheduling off-peak charging.

The Hierarchical maintenance design makes the maintenance and replacement much easier.

Compliant with OCPP 1.6 JSON and compatible with most of the charging network platforms in the European and UK market.

Over current, over voltage and short circuit protection, etc. make charging much safer.

JSON1.6 OCPP AC EV Charging Stations 7kW 22kw Home Charger

Protection

Rated Power 7.4kw,11kw,22kw
Type of connection 1P+N+PE,3P+N+PE,6-10mm2
Nominal Supply 230 VAC±15%,400VAC±15%
AC input frequency 50Hz/60Hz
Adjustable current 6A-32A Variable(Via APP)
Over Current protection 40A Supply(external MCB)
RCD protection Built-in Type B RCD DC 6 mA/AC 30 mA (Industrial-grade protection

Standby Power Consumption

Integrated protections

 <8W
Connectivity Bluetooth/WiFi/Ethernet/4G Optional/RS485/CAN Control charging with the LINCHR APP Built-in RFID reader,OCPP1.6
Solar Compatibility EO,EO+,and Fast charging modes

Load Balancing Installation network

 Up to 32 units can be connected
Supply Cable Entry TN, IT, and TT
Housing material/Enclosure O18mm-O24mm hole drilled at site through top and bottom of enclosure
Mounting Wall-mounting,pedestal mounting

JSON1.6 OCPP AC EV Charging Stations 7kW 22kw Home Charger
