IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock
IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock
IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock
IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock
IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock
IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock
Specifications
Brand Name :
ANS
Model Number :
ANS-T2S-32A
Certification :
TUV
Place of Origin :
China
MOQ :
1pcs
Price :
USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000pcs one day
Delivery Time :
15days
Packaging Details :
expoet standard package
product name :
EV Charging accessories
Rate :
32A
Voltage :
250V
standards :
IEC 62196-2
Material :
Thermoplastic
Type :
Extension Socket
Function :
Power Charging
customzation :
support customzation
power :
7kW
Description

Type 2 female sockets 32A 250V 7kW charging stations sockets with Hella Lock EV Charging accessories

Mechanical properties

Mechanical life: no-load plug >10000times

●Insertion force: <100N

Applied Materials

Shell material: thermoplastics,flame retardant grade UL94V-0

● Contact-tube: Copper alloy,silver platedSeal: Rubber,Silicone

Environmental performance

● Operating temperature:-30℃-+50℃

● Waterproof rate: IP55

Electrical Performance

● The rated current: 16A,32A,40A

● The rated voltage: 250V/440V

Insulation resistance∶>1000MΩ (DC500V)

● Pins temperature rise: <50K· Withstand voltage: 2000V

● Contact impedance∶ 0.5mΩMax

Features

1) Conform to the provisions and requirements of IEC62196-2 2016.

2) Match with Hela locking device.

3)Have one or two PTC(PT1000)thermistor (can match with NTCor Temperature control switch).

4)Beautfulappearance,preventioncap can be installed on theleft side,the right side or the fron ofi

5)Reliable material,flame retardant,pressure proof, wear-resisting.impact resistance,high oil proof

6)Excellent protection performance,protection grade achieved IP55 (working condition)).

Standards IEC62196-2 Standard
Rated Voltage 480V
waterproof IP55
warranty 12months
Mechanical life no-load plug in/pull out>10000times
Material Thermoplastic, copper terminal with sliver plating.

IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock

IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock

IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock

IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock

Package and shipping

IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock

Factory photos

IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock

Certification: TUV, CE,IATF16949,ISO 9001 Certification

IEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella LockIEC 62196-2 EV Charging Accessories Type 2 Female Socket With Hella Lock
