CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3
CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3
CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3
CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3
Specifications
Brand Name :
RUISU
Model Number :
RSDC1000-180KW
Certification :
CE ISO
Place of Origin :
GUANGZHOU,CHINA
MOQ :
1
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1500 Pcs Per Month
Delivery Time :
20-30 DAYS
Packaging Details :
Dimension (H*W*D)(mm) 830*620*1867
Input Frequency (Hz) :
45/66 Hz
Output Voltage Range (V) :
200-1000VDC
Max. Output Current (a) :
250A
Cable Length: Charger Gun :
5-7m(CCS2), Customized Acceptable
Protection Grade / Shell Material :
Outdoor IP54
Charging Operation :
Swiping card
Description

CE certificated 180KW CCS Chademo GBT OCPP level 3 Public EV charger electric car charging station EV charging station

180KW Fast DC EV Charger Pile for Electric Vehicle Highway Charging Station

Advantages:

1. Meet the charging requirements of all models of electric vehicles with different powers and dynamically

match the charging power required by the electric vehicles connected to any terminal.
2. Reduce energy consumption, improve the efficiency of the charging module, with more reasonable power

distribution, more stable power switching, and finer granularity.
3. Equip intelligent charging module, which has the advantages of high power, outstanding efficiency, low harmonics,

and high intelligence.
4. Dynamically allocate the charging power according to the charging demand from the BMS of the charging vehicle

to ensure charging safety.
5. Have dual charging ports to improve the efficiency of charging operation, and allow large battery vehicles to be charged

with two chargers.
6. Charging operation: swipe card / scan code; payment method: RFID card / WeChat/ Alipay.

Technical Parameters:

Product name 180KW All-in-one DC Charger
Dimension (H*W*D)(mm)
830*620*1867
Display Mode
7" Color Touch Screen
Input Frequency (HZ)
45~66Hz
Protection Grade / Shell Material
Outdoor IP54 / sheet metal shell
AC Input Voltage Range (V)
380±15%, 3 phases+N+PE
Power Factor
≥0.99
Communication Interface
4G
Heat Dissipation Control
Natural cooling
Charging Operation
Swiping card / scanning code
Protection Function
Lightning protection, over-load, short-circuit over-temperature, electric leakage, emergency stop protection etc.
MOQ Small order can be acceptable.
Delivery Time According to order qty.
Packaging Wooden box
Communication Protocol ocpp1.6
Charging Selection
Automatic, timing, quantitation, fixed fee, appointment etc
Running Indication
Power supply, charging, fault

CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3
After-sale Service:
1. Two years warranty for the whole body.
2. If any parts break during the period, it's free replacement.
3. Professional technical engineer support for installation&operation and communication connection assistance between your app and our OCPP platform.
Additional Options:
1. Customized cable length.
2. Customized charger connector.
3. Customized Box color and customized logo.

Factory Show

CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3

R&D and production

CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3

Production and Quality

CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3

Produce Department

CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3

Projects Case

CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3

Using Applications

CE certified Public Electric Vehicle Charging Stations CCS Chademo GBT OCPP level 3
